Control Techniques SP4403伺服驅動器

1.產 品 資 料 介 紹：

產品概述

Control Techniques SP4403 是一款 工業級伺服驅動器，屬于 Unidrive SP 系列。該驅動器專為精密伺服電機控制設計，提供高速、高精度的位置、速度和扭矩控制。SP4403 可與閉環伺服電機配合使用，實現高性能自動化運動控制，廣泛應用于機床、包裝設備、機器人及精密加工系統。

技術參數

• 型號：SP4403

• 類型：伺服驅動器 / AC Servo Drive

• 適配電機：三相伺服電機

• 額定功率：約 4 kW（具體依型號配置）

• 輸入電源：三相 380–480 V AC

• 控制方式：

  • 閉環矢量控制

  • 精確位置、速度及扭矩控制

• 反饋接口：支持編碼器（增量/絕對值）和旋轉變壓器

• 保護功能：過載、過壓、欠壓、短路、過溫保護

• 通信接口：支持 Modbus、CANopen、Ethernet/IP 等工業協議

• 安裝方式：模塊化設計，適合機柜或機架安裝

應用場景

1. 高精度機床：數控機床的伺服軸驅動

2. 機器人與自動化設備：工業機器人關節控制及搬運系統

3. 包裝機械：高速包裝機和分揀設備

4. 紡織與印刷設備：要求精確運動控制的生產設備

5. 實驗與研發：伺服控制測試及運動控制系統開發

產品優勢

1. 高性能控制：支持閉環矢量控制，實現高速響應和精確定位

2. 可靠性高：工業級設計，具備多重保護，保障電機與系統安全

3. 模塊化與靈活性：可與 Unidrive SP 系列驅動器集成，便于維護和升級

4. 豐富通信接口：輕松集成 PLC、DCS 或 SCADA 系統

5. 適用性強：可適配多種伺服電機，實現精密運動控制

Control Techniques SP4403伺服驅動器 英文資料：

Product Overview

Control Techniques SP4403 is an industrial grade servo drive belonging to the Unidrive SP series. This driver is designed specifically for precision servo motor control, providing high-speed, high-precision position, speed, and torque control. SP4403 can be used in conjunction with closed-loop servo motors to achieve high-performance automated motion control, and is widely used in machine tools, packaging equipment, robots, and precision machining systems.

Technical Specifications

Model: SP4403

Type: Servo Drive/AC Servo Drive

Suitable motor: three-phase servo motor

Rated power: approximately 4 kW (specific configuration according to model)

Input power supply: three-phase 380-480 V AC

Control method:

Closed-loop vector control

Accurate position, speed, and torque control

Feedback interface: Supports encoders (incremental/absolute) and rotary transformers

Protection functions: overload, overvoltage, undervoltage, short circuit, over temperature protection

Communication interface: Supports industrial protocols such as Modbus, CANopen, Ethernet/IP, etc

Installation method: Modular design, suitable for cabinet or rack installation

Application scenarios

High precision machine tools: servo axis drive for CNC machine tools

Robots and Automation Equipment: Joint Control and Handling Systems for Industrial Robots

Packaging machinery: high-speed packaging machines and sorting equipment

Textile and printing equipment: production equipment that requires precise motion control

Experiment and research and development: servo control testing and motion control system development

Product advantages

High performance control: supports closed-loop vector control, achieving high-speed response and precise positioning

High reliability: Industrial grade design with multiple protections to ensure the safety of motors and systems

Modularity and flexibility: Can be integrated with Unidrive SP series drives for easy maintenance and upgrades

Rich communication interfaces: easy integration of PLC, DCS or SCADA systems

Strong applicability: can adapt to various servo motors to achieve precise motion control

Control Techniques SP4403伺服驅動器 產品展示

 產品視頻
