GE 193X238AAG01信號隔離器
1.產 品 資 料 介 紹：
中文資料：
193X238AAG01 信號隔離器（Signal Isolator）
產品概述
193X238AAG01 是 GE（General Electric）193X 系列工業控制板卡中的一款專用信號隔離器模塊，主要用于模擬或數字信號在不同電位系統之間的安全隔離與傳輸。它可防止接地回路干擾、電氣噪聲或高壓反灌影響主控系統，確保控制系統的穩定與可靠運行。
主要功能特點
信號電氣隔離：實現輸入與輸出通道之間的完全電氣隔離，典型隔離電壓可達 2500V。
多種信號兼容：支持電壓、電流、開關量等多種工業信號形式。
低漂移、高精度：內部采用精密隔離放大器，保持輸入信號的線性度與準確性。
增強型抗干擾：內置濾波與抑噪電路，特別適合高干擾工業環境應用。
板載診斷功能：具備信號故障指示，可監測輸入異常、信號中斷等狀態。
技術參數
輸入信號：0–10V DC、4–20mA、±5V、±10V（依據配置）
輸出信號：與輸入線性對應，電壓或電流形式
隔離電壓：最小 1500V RMS，典型 2500V RMS（輸入-輸出-電源間）
響應時間：<10ms，適用于工業控制實時反饋
精度：±0.1% FS，適合精密控制場合
溫度范圍：-20°C 至 +70°C
電源要求：±15V DC 或 24V DC（由系統母板供電）
安裝結構：插槽式安裝，兼容 GE 193X 控制架系統
英文資料：
193X238AAG01 Signal Isolator
product overview
193X238AAG01 is a dedicated signal isolator module in the GE (General Electric) 193X series industrial control board, mainly used for safe isolation and transmission of analog or digital signals between different potential systems. It can prevent interference from grounding circuits, electrical noise, or high voltage backflow from affecting the main control system, ensuring the stable and reliable operation of the control system.
Main functional features
Signal electrical isolation: achieving complete electrical isolation between input and output channels, with a typical isolation voltage of up to 2500V.
Multiple signal compatibility: supports various industrial signal forms such as voltage, current, and switch quantity.
Low drift, high precision: The internal adopts a precision isolation amplifier to maintain the linearity and accuracy of the input signal.
Enhanced anti-interference: Built in filtering and noise suppression circuit, especially suitable for high interference industrial environment applications.
Onboard diagnostic function: It has signal fault indication and can monitor input abnormalities, signal interruptions, and other states.
Technical Parameter
Input signal: 0-10V DC, 4-20mA, ± 5V, ± 10V (depending on configuration)
Output signal: linearly corresponding to the input, in the form of voltage or current
Isolation voltage: minimum 1500V RMS, typical 2500V RMS (input-output power supply)
Response time:< 10ms, suitable for real-time feedback in industrial control
Accuracy: ± 0.1% FS, suitable for precision control applications
Temperature range:- 20 ° C to+70 ° C
Power requirement: ± 15V DC or 24V DC (powered by the system motherboard)
Installation structure: slot type installation, compatible with GE 193X control rack system
