AEG MODICON MM-PM10-200操作員顯示面板
1.產 品 資 料 介 紹：
- 工業級專用人機交互終端，專為 Modicon PM 系列控制系統定制，操作邏輯深度適配工業場景。
- 配備 10 英寸高清液晶顯示屏幕，分辨率達 800×480，色彩還原度高，復雜工藝參數清晰呈現。
- 支持多點電容觸摸操作，響應靈敏度＜5ms，同時兼容實體按鍵，適配戴手套或惡劣環境作業需求。
- 原生兼容 Modicon PM 系列及 984 系列控制器，背板總線直連無需轉接模塊，即插即用。
- 內置 8GB 本地存儲，可緩存歷史運行數據、故障日志及工藝配方，支持離線查看與導出。
- 支持自定義界面布局，可根據行業需求編輯專屬操作頁面，常用功能一鍵直達，提升操作效率。
- 工業級防護設計，防護等級達 IP65，耐受粉塵、油污及飛濺水滴，適配車間、戶外等多元場景。
- 24VDC 寬壓供電，內置過壓、反接保護電路，電壓波動 ±10% 范圍內仍能穩定運行。
- 集成聲光報警模塊，支持自定義報警閾值與提示方式，異常狀態快速預警，避免生產風險。
- 支持 Modbus RTU/TCP 通信協議，可遠程對接上位機監控系統，實現集中化運維管理。
- 屏幕采用防眩光、防刮擦鋼化玻璃，強光環境下可視性不受影響，使用壽命延長至 8 萬小時。
- 支持多用戶權限管理，區分操作員、工程師、管理員權限，防止關鍵參數誤修改，保障生產安全。
- 緊湊型設計，厚度僅 25mm，支持嵌入式面板安裝，節省控制柜空間，適配密集布局需求。
- 作為 PM 系列存量系統核心備件，替換舊款顯示面板無需重構控制程序，更換時間＜30 分鐘。
- 廣泛適配機械制造、化工過程控制、能源監測、自動化生產線等場景，人機交互體驗專業高效。
AEG MODICON MM-PM10-200操作員顯示面板 英文資料：
Industrial grade dedicated human-machine interaction terminal, customized for Modicon PM series control systems, with operation logic deeply adapted to industrial scenarios.
Equipped with a 10 inch high-definition LCD display screen, with a resolution of 800 × 480, high color reproduction, and clear presentation of complex process parameters.
Support multi-point capacitive touch operation, response sensitivity<5ms, compatible with physical buttons, suitable for wearing gloves or working in harsh environments.
Native compatible with Modicon PM series and 984 series controllers, the backplane bus is directly connected without the need for adapter modules, plug and play.
Built in 8GB local storage, capable of caching historical operational data, fault logs, and process formulas, supporting offline viewing and export.
Support custom interface layout, edit exclusive operation pages according to industry needs, and provide one click access to commonly used functions to improve operational efficiency.
Industrial grade protection design, with a protection level of IP65, resistant to dust, oil stains, and splashing water droplets, suitable for various scenarios such as workshops and outdoors.
24VDC wide voltage power supply, built-in overvoltage and reverse protection circuit, stable operation within ± 10% voltage fluctuation range.
Integrated sound and light alarm module, supports custom alarm thresholds and prompt methods, quickly alerts for abnormal states, and avoids production risks.
Supports Modbus RTU/TCP communication protocol, can remotely interface with upper computer monitoring system, and achieve centralized operation and maintenance management.
The screen is made of anti glare and scratch resistant tempered glass, ensuring visibility in strong light environments and extending its lifespan to 80000 hours.
Support multi-user permission management, distinguish between operator, engineer, and administrator permissions, prevent erroneous modification of key parameters, and ensure production safety.
Compact design, with a thickness of only 25mm, supports embedded panel installation, saves control cabinet space, and adapts to dense layout requirements.
As a core spare part of the PM series inventory system, replacing the old display panel does not require restructuring the control program, and the replacement time is less than 30 minutes.
Widely adaptable to scenarios such as mechanical manufacturing, chemical process control, energy monitoring, automated production lines, etc., with professional and efficient human-machine interaction experience.
AEG MODICON MM-PM10-200操作員顯示面板 產品展示
