AMAT Applied Materials 0090-02287電氣組件
1.產 品 資 料 介 紹：
- 多類型接口集成適配：集成電力接口（如端子式電源接口、插頭式高壓接口）與信號接口（如針式信號接口、RJ45 數據接口），可同時對接設備電源模塊、控制單元（如 PLC）、傳感器與執行機構（如伺服電機），無需額外轉接組件，簡化設備內部布線，減少連接節點，降低信號衰減與電力損耗風險，確保電力傳輸效率≥95%，信號傳輸誤差≤0.1%。
- 低阻抗電力傳輸設計：采用高純度電解銅導電材質（電阻率≤1.72×10??Ω?m），導電端子厚度≥0.5mm，接觸面經鍍錫處理（錫層厚度≥5μm），降低接觸電阻（接觸電阻≤10mΩ），減少電流傳輸過程中的熱量產生；同時根據設備功率需求優化導線截面積（電力線路截面積≥1.5mm2，信號線路截面積≥0.5mm2），可承載最大 30A 工作電流，滿足半導體設備高功率模塊（如加熱腔、射頻電源）的電力供應需求。
- 信號與電力隔離布局：采用分層隔離設計，將電力線路與信號線路分區域布置，區域間設置金屬屏蔽隔板（屏蔽效能≥40dB），防止電力線路產生的電磁干擾影響信號傳輸；同時信號線路采用雙絞線或屏蔽線纜，進一步增強抗干擾能力，確保傳感器采集的微弱信號（如 mV 級溫度信號）在復雜電磁環境下仍能穩定傳輸，避免因信號干擾導致的設備控制偏差。
- 電氣安全保護功能：集成過電流保護（采用自恢復保險絲，額定電流根據線路需求配置，過載時 1 秒內切斷電路）、過電壓保護（TVS 二極管，擊穿電壓≥1.2 倍額定電壓，響應時間≤10ns）與短路保護（快速熔斷保險絲，分斷能力≥10kA），當電路出現過流、過壓或短路時，可迅速切斷故障線路，保護下游設備模塊（如控制芯片、傳感器），避免因電氣故障導致的設備損壞與晶圓報廢。
AMAT Applied Materials 0090-02287電氣組件 英文資料：
1、 Efficient electrical connection: ensuring precise transmission of power and signals in semiconductor equipment
As the "electrical hub" of semiconductor equipment, 0090-02287 electrical components have stable and efficient connection capabilities as their core, achieving dual functions of internal power distribution and signal interaction:
Multi type interface integration and adaptation: Integrating power interfaces (such as terminal power interfaces, plug type high-voltage interfaces) and signal interfaces (such as pin type signal interfaces, RJ45 data interfaces), it can simultaneously interface with equipment power modules, control units (such as PLCs), sensors, and actuators (such as servo motors) without the need for additional adapter components, simplifying internal wiring of equipment, reducing connection nodes, reducing signal attenuation and power loss risks, ensuring power transmission efficiency ≥ 95% and signal transmission error ≤ 0.1%.
Low impedance power transmission design: using high-purity electrolytic copper conductive material (resistivity ≤ 1.72 × 10 ??Ω· m), conductive terminal thickness ≥ 0.5mm, contact surface treated with tin plating (tin layer thickness ≥ 5 μ m), reducing contact resistance (contact resistance ≤ 10m Ω), and minimizing heat generation during current transmission; At the same time, the cross-sectional area of the wires is optimized according to the power requirements of the equipment (power line cross-sectional area ≥ 1.5mm 2, signal line cross-sectional area ≥ 0.5mm 2), which can carry a maximum working current of 30A and meet the power supply needs of high-power modules of semiconductor equipment (such as heating chambers and RF power supplies).
Signal and power isolation layout: Adopting a layered isolation design, power lines and signal lines are arranged in different areas, and metal shielding partitions (shielding effectiveness ≥ 40dB) are set up between areas to prevent electromagnetic interference generated by power lines from affecting signal transmission; At the same time, the signal line adopts twisted pair or shielded cables to further enhance anti-interference ability, ensuring that weak signals collected by sensors (such as mV level temperature signals) can still be stably transmitted in complex electromagnetic environments, avoiding equipment control deviations caused by signal interference.
2、 Comprehensive safety protection: safeguarding the electrical safety of semiconductor equipment
In response to the high voltage and high power operating characteristics of semiconductor equipment, this electrical component has constructed multiple safety protection systems to reduce the risk of electrical failures:
Electrical safety protection function: Integrated overcurrent protection (using self recovering fuses, rated current configured according to line requirements, circuit can be cut off within 1 second in case of overload), overvoltage protection (TVS diode, breakdown voltage ≥ 1.2 times rated voltage, response time ≤ 10ns) and short-circuit protection (quick melting fuse, breaking capacity ≥ 10kA). When overcurrent, overvoltage or short circuit occurs in the circuit, the faulty line can be quickly cut off to protect downstream equipment modules (such as control chips and sensors), avoiding equipment damage and wafer scrap caused by electrical faults.
