AMAT Applied Materials  0100-00014檢測PCB

1.產 品 資 料 介 紹：

AMAT Applied Materials  0100-00014檢測PCB  英文資料：

1、 Full scene detection function: covering key parameter monitoring of equipment

As the "state perception core" of semiconductor equipment, 0100-00014 PCB detection is based on multi-dimensional parameter acquisition, real-time monitoring of equipment electrical performance, component status, and environmental parameters, providing accurate data support for equipment health diagnosis and fault warning:

High precision detection of electrical parameters

Integrate multiple types of electrical detection units to achieve real-time collection of core electrical parameters of equipment:

Voltage detection: Equipped with a 16 bit high-precision ADC (Analog to Digital Converter), supporting 0-300V AC/DC voltage detection with a measurement accuracy of ± 0.1% F.S. It can monitor key parameters such as power module output voltage and interface terminal voltage. The voltage fluctuation capture resolution is ≤ 1mV, and power supply abnormalities (such as voltage drift and excessive ripple) can be detected in a timely manner;

Current detection: By combining Hall current sensors with shunt resistors, it supports 0-50A AC/DC current detection with a measurement accuracy of ± 0.2% F.S. It can monitor motor drive current, heating circuit current, etc. The response time to current changes is ≤ 10 μ s, avoiding component burnout caused by overcurrent;

Power and energy consumption detection: Real time calculation of power (accuracy ± 0.3% F.S.) based on voltage and current detection data, and accumulation of equipment energy consumption (measurement accuracy ± 1%). It supports statistical energy consumption data by time period (such as hours, days), providing a basis for optimizing equipment energy efficiency and meeting the green production needs of the semiconductor industry.

Component status and signal detection

Build specialized detection capabilities for key components and signal links of equipment:

Sensor signal verification: equipped with 8 sensor signal detection channels, compatible with thermocouples (K-type, J-type) RTD（PT100/PT1000）、 Output signals from pressure sensors (4-20mA) can verify the integrity and accuracy of sensor signals, with a detection error of ≤± 0.2% F.S., to avoid misjudgment of process parameters caused by sensor failures;

Interface signal monitoring: supports signal quality detection of communication interfaces such as RS485, Ethernet, CAN, etc., including signal amplitude (measurement range 0-5V, accuracy ± 5mV), transmission rate (0-1000Mbps), bit error rate (detection lower limit 10 ??), can capture interface signal attenuation, interference and other issues in real time, ensuring stable data transmission;

Switch status and logic detection: Integrated with 16 digital input detection channels (compatible with TTL/CMOS levels), monitoring the on/off status of switch components such as relays and solenoid valves. The response time to state changes is ≤ 1 μ s, which can quickly identify faults such as component jamming and contact adhesion, and avoid equipment action disorder.

AMAT Applied Materials  0100-00014檢測PCB 產品展示
