AMAT Applied Materials 0190-22543網關模塊
1.產 品 資 料 介 紹：
- 工業級協議全覆蓋：支持半導體設備常用的各類工業協議，包括現場總線協議（如 Profinet、EtherNet/IP、Modbus RTU/TCP）、設備專用協議（如 AMAT 設備私有通信協議、SECS/GEM 半導體標準協議）及通用網絡協議（如 TCP/IP、MQTT），可同時對接設備內部的 PLC、傳感器、驅動器與外部的工廠 MES 系統、云端管理平臺，無需額外協議轉換模塊，解決不同設備、系統間的 “數據孤島” 問題。
- 高速數據傳輸能力：采用千兆以太網接口（傳輸速率 1000Mbps）與工業級通信芯片，數據轉發延遲≤10ms，單模塊最大并發連接數≥100，可滿足半導體設備 24 小時連續運行中高頻數據（如晶圓加工參數、設備狀態信息）的實時傳輸需求，確保工藝數據無丟失、無延遲，為生產過程監控與質量追溯提供精準數據支撐。
- 雙向數據交互控制：支持 “數據采集 + 指令下發” 雙向交互，既能實時采集設備運行參數（如溫度、壓力、晶圓傳輸進度）并上傳至管理系統，也能接收系統下發的控制指令（如工藝程序切換、設備啟停信號）并轉發至設備執行模塊，實現對半導體設備的遠程監控與精準控制，提升生產自動化水平。
- 數據傳輸加密：采用 AES-256 對稱加密算法與 RSA 非對稱加密算法，對設備與系統間傳輸?shù)乃袛?shù)據（包括工藝參數、控制指令）進行端到端加密，防止數據在傳輸過程中被竊取或篡改；同時支持 SSL/TLS 安全通信協議，保障網絡傳輸鏈路安全，符合半導體行業數據保密標準（如 ISO 27001 信息安全管理體系）。
AMAT Applied Materials 0190-22543網關模塊 英文資料：
1、 Multi protocol compatible data exchange: Connecting semiconductor device data links
As the "data translation hub" of semiconductor devices, the 0190-22543 gateway module is based on the ability to adapt protocols to all scenarios, achieving seamless data interconnection between internal modules and external systems of the device
Full coverage of industrial level protocols: Supports various industrial protocols commonly used in semiconductor devices, including fieldbus protocols (such as Profinet, EtherNet/IP, Modbus RTU/TCP), device specific protocols (such as AMAT device private communication protocol, SECS/GEM semiconductor standard protocol), and general network protocols (such as TCP/IP, MQTT). It can simultaneously interface with internal PLCs, sensors, drivers, external factory MES systems, and cloud management platforms without the need for additional protocol conversion modules, solving the problem of "data silos" between different devices and systems.
High speed data transmission capability: using Gigabit Ethernet interface (transmission rate 1000Mbps) and industrial grade communication chip, data forwarding delay ≤ 10ms, maximum concurrent connections per module ≥ 100, can meet the real-time transmission requirements of high-frequency data (such as wafer processing parameters and equipment status information) in 24-hour continuous operation of semiconductor equipment, ensuring no loss or delay of process data, and providing accurate data support for production process monitoring and quality traceability.
Bidirectional data exchange control: supports "data acquisition+instruction issuance" bidirectional interaction, which can not only real-time collect equipment operating parameters (such as temperature, pressure, wafer transfer progress) and upload them to the management system, but also receive control instructions issued by the system (such as process program switching, equipment start stop signals) and forward them to the equipment execution module, realizing remote monitoring and precise control of semiconductor equipment, and improving the level of production automation.
2、 High reliability network security protection: safeguarding semiconductor core data
In response to the high confidentiality of process data and high security of equipment control in the semiconductor industry, this gateway module has built a multi-level security protection system:
Data transmission encryption: AES-256 symmetric encryption algorithm and RSA asymmetric encryption algorithm are used to encrypt all data (including process parameters and control instructions) transmitted between devices and systems end-to-end, preventing data from being stolen or tampered with during transmission; Simultaneously supporting SSL/TLS secure communication protocols, ensuring the security of network transmission links, and complying with data confidentiality standards in the semiconductor industry (such as ISO 27001 Information Security Management System).
AMAT Applied Materials 0190-22543網關模塊 產品展示
產品視頻
