AMAT Applied Materials 9101-1745伺服驅動器

1.產 品 資 料 介 紹：

AMAT Applied Materials 9101-1745 伺服驅動器

核心技術參數

產品特點

• 高精度控制：采用先進的伺服控制算法，實現納米級定位精度
• 快速響應：高速處理器與優化控制環路，確保動態響應迅速
• 穩定可靠：工業級設計，適應半導體設備嚴苛工作環境
• 靈活配置：支持多種控制模式和反饋類型，滿足不同應用需求
• 完善保護：全面的電氣保護功能，確保設備安全運行

典型應用

• 晶圓傳輸機器人的精確位置控制
• 光刻機工作臺的高速定位系統
• 刻蝕 / 沉積設備的精密運動機構
• 檢測設備的自動對準系統

安裝與維護建議

1. 安裝前準備
   • 確認電源規格與驅動器匹配
   • 檢查電機參數與驅動器設置一致
   • 確認編碼器類型與接線正確
2. 調試要點
   • 先進行電機識別和參數自整定
   • 逐步調整控制參數，優化動態性能
   • 設置合理的軟限位和保護參數

AMAT Applied Materials 9101-1745伺服驅動器 英文資料：

AMAT Applied Materials 9101-1745 Servo Drive

AMAT 9101-1745 is a high-performance servo driver designed specifically for semiconductor manufacturing equipment, used for precise control of servo motors to achieve high-precision motion control of wafer transfer systems, robotic arms, and precision positioning mechanisms.

Core technical parameters

Project specifications

Three control modes: position, speed, and torque

Motor type supports DC/AC servo motors

Feedback Interface Encoder Interface (Incremental/Absolute)

Communication interface RS-485/Industrial Ethernet (by model)

Power supply voltage 24-48VDC or 200-240VAC

The control accuracy can reach 1/1000 of the encoder resolution

Protection function: overcurrent/overvoltage/overheating/overload protection

Working environment 0-55 ° C, relative humidity 20-80%

Product Features

High precision control: using advanced servo control algorithms to achieve nanometer level positioning accuracy

Fast response: High speed processor and optimized control loop ensure rapid dynamic response

Stable and reliable: Industrial grade design, suitable for harsh working environments of semiconductor equipment

Flexible configuration: supports multiple control modes and feedback types to meet different application needs

Complete protection: Comprehensive electrical protection function to ensure safe operation of equipment

Typical Applications

Accurate position control of wafer transfer robot

High speed positioning system for lithography machine workbench

Precision motion mechanism of etching/deposition equipment

Automatic alignment system for detection equipment

Installation and maintenance recommendations

Pre-installation preparation

Confirm that the power specifications match the driver

Check that the motor parameters are consistent with the driver settings

Confirm that the encoder type and wiring are correct

Debugging points

First, perform motor identification and parameter self-tuning

Gradually adjust control parameters to optimize dynamic performance

Set reasonable soft limit and protection parameters

AMAT Applied Materials  9101-1745伺服驅動器 產品展示
