AMAT  0190-27748控制視頻開關

1.產 品 資 料 介 紹：

AMAT 0190-27748 控制視頻開關

產品概述

AMAT（Applied Materials）0190-27748 控制視頻開關是一種用于半導體制造設備的 視頻信號切換與控制模塊。它主要用于監控設備內部工藝或機械動作，通過切換多個視頻信號源，將攝像頭、監控探頭或工藝觀察點的圖像信號傳輸?shù)讲僮鹘缑婊蛴涗浵到y(tǒng)，實現設備狀態監控、工藝觀察和安全管理。

技術參數（典型方向，具體數據需參考原廠資料）

• 輸入/輸出：多路視頻輸入，多路輸出，可選擇切換

• 信號類型：模擬或數字視頻信號

• 控制方式：通過控制系統或手動接口切換視頻源

• 接口：與設備監控系統、控制器或操作終端連接

• 安裝方式：模塊化設計，可集成于控制箱或設備底盤

• 環境適應性：適應潔凈室環境及工業溫度范圍

應用場景

1. 沉積工藝（CVD/PVD/ALD）

   • 監控反應腔體或關鍵模塊狀態

   • 實時觀察沉積過程，確保工藝精度

2. 刻蝕工藝設備

   • 切換觀察刻蝕腔體或氣體流量控制點的監控視頻

   • 支持工藝參數調整和異常排查

3. 離子注入系統

   • 實時監控離子源、掃描系統及束流路徑

   • 提高注入過程的可視化和操作安全

4. 設備維護與操作

   • 切換監控視角，便于現場維護和故障診斷

   • 支持操作人員快速定位設備異常

5. 工廠自動化與安全管理

   • 與互鎖系統和操作界面結合，實現遠程監控

   • 提高設備運行安全性和工藝可控性

AMAT  0190-27748控制視頻開關 英文資料：

AMAT 0190-27748 Control Video Switch

Product Overview

AMAT (Applied Materials) 0190-27748 Control Video Switch is a video signal switching and control module used in semiconductor manufacturing equipment. It is mainly used to monitor the internal processes or mechanical movements of equipment. By switching multiple video signal sources, the image signals of cameras, monitoring probes, or process observation points are transmitted to the operation interface or recording system to achieve equipment status monitoring, process observation, and safety management.

Technical parameters (typical direction, specific data should refer to the original factory information)

Input/Output: Multiple video inputs, multiple outputs, switchable

Signal type: Analog or digital video signal

Control method: Switch the video source through the control system or manual interface

Interface: Connect with device monitoring system, controller or operation terminal

Installation method: Modular design, can be integrated into the control box or equipment chassis

Environmental adaptability: Suitable for clean room environment and industrial temperature range

Application scenarios

Deposition process (CVD/PVD/ALD)

Monitor the status of reaction chambers or critical modules

Real time observation of sedimentation process to ensure process accuracy

Etching process equipment

Switching between monitoring videos for observing etching chambers or gas flow control points

Support process parameter adjustment and abnormal troubleshooting

Ion implantation system

Real time monitoring of ion source, scanning system, and beam path

Improve the visualization and operational safety of the injection process

Equipment maintenance and operation

Switching monitoring perspectives for easy on-site maintenance and fault diagnosis

Support operators to quickly locate equipment abnormalities

Factory Automation and Safety Management

Combined with interlocking system and operation interface, achieve remote monitoring

Improve equipment operation safety and process controllability

AMAT 0190-27748控制視頻開關  產品展示

 產品視頻
