ALCATEL LUCENT  3AL36010AAAB繼電器

1.產 品 資 料 介 紹：

中文資料：

ALCATEL LUCENT 3AL36010AAAB
繼電器功能模塊（Relay Board）

產品概述：

3AL36010AAAB 在特定 Alcatel-Lucent 系統中也可能集成有 繼電器控制功能，通常用于電信設備中的控制電路，用以實現信號切換、設備狀態響應、線路保護等功能。

此類模塊具備多組可控繼電器輸出，可被控制系統通過程控指令遠程控制，從而影響電源、通信線路或其他設備狀態，廣泛用于運營商機房、基站和接入節點設備。

核心功能特點：

• 多通道繼電器輸出：支持多路繼電器通道，可單獨控制開關狀態。

• 遠程控制與響應機制：繼電器動作可由主控板發出命令遠程觸發，具備自動故障響應能力。

• 過流保護設計：內部具備對繼電器觸點的電流過載保護功能，防止電路損壞。

• 狀態指示功能：繼電器狀態可實時反饋至系統監控軟件，用于診斷和維護。

• 高電氣隔離性：具備良好的光電隔離/磁隔離能力，適合信號與強電分離的工業環境。

典型應用領域：

1. 通信設備電源切換控制

   • 在阿爾卡特朗訊通信機架中控制整流器、UPS 電源或負載側通斷。

2. 遠程重啟與故障轉移

   • 實現對遠端通信單元的斷電重啟，或在故障情況下切換至備用電路。

3. 設備告警與狀態控制

   • 與系統告警模塊聯動，在通信異常時觸發繼電器動作，點亮信號燈或報警蜂鳴器。

4. 工業自動化信號控制

   • 應用于 Alcatel Lucent 控制系統接入工業現場設備，實現繼電器級聯動作。

5. 安全聯鎖系統

   • 用于通信系統中實現硬件聯鎖，避免誤操作或非法接入。

英文資料：

ALCATEL LUCENT 3AL36010AAAB

Relay Board Function Module

Product Overview:

3AL36010AAB may also be integrated with relay control functions in specific Alcatel Lucent systems, typically used in control circuits in telecommunications equipment to achieve signal switching, device status response, line protection, and other functions.

This type of module has multiple sets of controllable relay outputs, which can be remotely controlled by the control system through programmable instructions, thereby affecting the status of power supply, communication lines or other equipment. It is widely used in operator rooms, base stations and access node equipment.

Core functional features:

Multi channel relay output: Supports multiple relay channels and can independently control switch status.

Remote control and response mechanism: Relay action can be remotely triggered by commands issued by the main control board, with automatic fault response capability.

Overcurrent protection design: It has an internal current overload protection function for relay contacts to prevent circuit damage.

Status indication function: The relay status can be fed back in real-time to the system monitoring software for diagnosis and maintenance.

High electrical isolation: It has good photoelectric/magnetic isolation capabilities and is suitable for industrial environments where signals and strong electricity are separated.

Typical application areas:

Communication equipment power switching control

Control the on/off of rectifiers, UPS power supplies, or load side in Alcatel Lucent communication racks.

Remote restart and failover

Implement power-off and restart of remote communication units, or switch to backup circuits in case of faults.

Equipment alarm and status control

Linked with the system alarm module, it triggers relay action and lights up the signal light or alarm buzzer in case of communication abnormalities.

Industrial automation signal control

Applied to Alcatel Lucent control system connected to industrial field equipment to achieve relay cascade action.

Safety Interlock System

Used to implement hardware interlocking in communication systems to avoid misoperation or illegal access.

2.產      品      展      示
