Control Techniques M751-03400160A逆變器

1.產 品 資 料 介 紹：

產品概述

Control Techniques M751-03400160A 屬于 Digitax HD 系列高性能交流伺服逆變器，專為高動態、高精度工業應用設計。它可提供快速加速和高峰值扭矩輸出，適用于工業自動化設備、機床、機器人及包裝機械等精密運動控制系統。

技術參數

• 型號：M751-03400160A

• 系列：Digitax HD

• 電機類型：三相交流伺服電機

• 額定功率：約 5.5 kW（7.5 hp）

• 額定輸出電流：16.0 A

• 輸入電源：三相 380–480 V AC

• 控制方式：閉環矢量控制，支持位置、速度及扭矩控制

• 通信接口：RS485，支持 Modbus RTU 等協議

• 安裝方式：機柜安裝，IP20 防護等級

• 擴展功能：提供擴展槽，可增加安全模塊或其他功能模塊

應用場景

1. 工業機器人：關節驅動與搬運系統

2. 高精度機床：數控機床伺服軸控制

3. 包裝機械：高速包裝機及分揀設備

4. 紡織與印刷設備：精確運動控制

5. 研發實驗：伺服控制測試及運動控制系統開發

產品優勢

1. 高動態性能：支持高峰值扭矩輸出，滿足快速加減速需求

2. 精密控制：閉環矢量控制，實現速度、扭矩和位置的高精度控制

3. 可靠性高：工業級設計，散熱和保護機制完善，適合連續高負載運行

4. 模塊化與擴展性強：可增加功能模塊，如安全模塊或通信擴展

5. 緊湊設計：適合機柜安裝，節省空間，易于工業環境集成

Control Techniques  M751-03400160A逆變器  英文資料：

Product Overview

Control Techniques M751-03400160A belongs to the Digitax HD series high-performance AC servo inverters, designed specifically for high dynamic and high-precision industrial applications. It can provide fast acceleration and high peak torque output, suitable for precision motion control systems such as industrial automation equipment, machine tools, robots, and packaging machinery.

Technical Specifications

Model: M751-03400160A

Series: Digitax HD

Motor type: Three phase AC servo motor

Rated power: approximately 5.5 kW (7.5 hp)

Rated output current: 16.0 A

Input power supply: three-phase 380-480 V AC

Control mode: closed-loop vector control, supporting position, speed, and torque control

Communication interface: RS485, supports Modbus RTU and other protocols

Installation method: Cabinet installation, IP20 protection level

Expansion function: Provides expansion slots to add security modules or other functional modules

Application scenarios

Industrial Robots: Joint Drive and Handling Systems

High precision machine tools: servo axis control for CNC machine tools

Packaging Machinery: High speed Packaging Machines and Sorting Equipment

Textile and Printing Equipment: Precise Motion Control

Research and Development Experiment: Servo Control Testing and Motion Control System Development

Product advantages

High dynamic performance: supports high peak torque output to meet rapid acceleration and deceleration requirements

Precision control: closed-loop vector control, achieving high-precision control of speed, torque, and position

High reliability: Industrial grade design, complete heat dissipation and protection mechanisms, suitable for continuous high load operation

Strong modularity and scalability: can add functional modules such as security modules or communication extensions

Compact design: suitable for cabinet installation, saves space, and is easy to integrate into industrial environments

Control Techniques M751-03400160A逆變器 產品展示

 產品視頻
