Control Techniques SP2401伺服驅動器

1.產 品 資 料 介 紹：

產品概述

Control Techniques SP2401 是一款 工業級伺服驅動器，隸屬于 Unidrive SP 系列。該驅動器專為閉環伺服電機設計，提供精確的速度、扭矩和位置控制。SP2401 適用于高性能自動化設備、機床、包裝機械以及機器人系統，確保運動控制平穩、響應快速、定位準確。

技術參數

• 型號：SP2401

• 類型：伺服驅動器 / AC Servo Drive

• 適配電機：三相伺服電機

• 額定功率：約 2.4 kW（根據具體型號配置可能略有差異）

• 輸入電源：三相 380–480 V AC

• 控制方式：

  • 閉環矢量控制

  • 精確位置、速度和扭矩控制

• 反饋接口：支持編碼器（增量式/絕對式）

• 保護功能：過載、過壓、欠壓、短路、過溫保護

• 通信接口：支持 Modbus、CANopen、Ethernet/IP 等工業協議

• 安裝方式：模塊化設計，可機柜或機架安裝

應用場景

1. 高精度機床：數控機床主軸或伺服軸驅動

2. 工業機器人：關節及搬運運動控制

3. 包裝機械：高速包裝機及分揀設備

4. 紡織、印刷設備：要求精準運動控制的生產設備

5. 實驗與研發：伺服運動控制測試及實驗平臺

Control Techniques  SP2401伺服驅動器 英文資料：

Product Overview

Control Techniques SP2401 is an industrial grade servo drive belonging to the Unidrive SP series. This driver is designed specifically for closed-loop servo motors, providing precise speed, torque, and position control. SP2401 is suitable for high-performance automation equipment, machine tools, packaging machinery, and robot systems, ensuring smooth motion control, fast response, and accurate positioning.

Technical Specifications

Model: SP2401

Type: Servo Drive/AC Servo Drive

Suitable motor: three-phase servo motor

Rated power: approximately 2.4 kW (may vary slightly depending on the specific model configuration)

Input power supply: three-phase 380-480 V AC

Control method:

Closed-loop vector control

Accurate position, speed, and torque control

Feedback interface: Supports encoders (incremental/absolute)

Protection functions: overload, overvoltage, undervoltage, short circuit, over temperature protection

Communication interface: Supports industrial protocols such as Modbus, CANopen, Ethernet/IP, etc

Installation method: Modular design, can be installed in cabinets or racks

Application scenarios

High precision machine tools: CNC machine tool spindle or servo axis drive

Industrial Robots: Joint and Handling Motion Control

Packaging Machinery: High speed Packaging Machines and Sorting Equipment

Textile and printing equipment: production equipment that requires precise motion control

Experiment and R&D: Servo motion control testing and experimental platform

Control Techniques  SP2401伺服驅動器 產品展示

 產品視頻
