GIDINGS&LEWIS  503-19185-01編碼輸入模塊

1.產 品 資 料 介 紹：

GIDINGS&LEWIS 503-19185-01 編碼輸入模塊

產品概述

技術特點

高精準信號處理

多類型編碼器兼容

高速信號傳輸

英文資料：

GIDINGS&LEWIS 503-19185-01 Encoding Input Module

Product Overview

In industrial automation control systems, the GIDINGS&LEWIS 503-19185-01 encoding input module is an important bridge connecting the encoder and the upper control system. It is mainly responsible for receiving position, velocity and other signals from various rotary encoders, processing and converting these signals into standard signals that can be recognized and utilized by the upper control system, providing key feedback data for precise control of industrial equipment, and is one of the core components for achieving closed-loop control and high-precision motion control.

Technical Features

High precision signal processing

The GIDINGS&LEWIS 503-19185-01 encoding input module has excellent high-precision signal processing capabilities, which can accurately capture weak signals output by rotary encoders and perform filtering, shaping, amplification and other processing on them. Whether it is the pulse signal output by the incremental encoder or the position encoded signal output by the absolute encoder, it can accurately identify and analyze, ensuring the integrity and accuracy of the signal. In high-precision CNC machine tools, this precise signal processing capability ensures that real-time monitoring errors of tool position and spindle speed are controlled within a very small range, providing strong guarantees for machining accuracy.

Compatible with multiple types of encoders

This module has excellent compatibility and can adapt to various types and specifications of rotary encoders. Whether it is an optical encoder, a magneto electric encoder, or encoders with different resolutions and output modes (such as TTL, HTL), they can all be stably connected and work normally. This broad compatibility allows it to be flexibly applied in various industrial equipment, without the need to ｒｅｐｌａｃｅ modules due to different encoder types, reducing the difficulty of equipment selection and maintenance.

High speed signal transmission

By adopting advanced circuit design and signal processing technology, the GIDINGS&LEWIS 503-19185-01 encoding input module has high-speed signal transmission capability. It can quickly receive and process high-frequency pulse signals emitted by encoders, ensuring that the signals are not lost or delayed even when the equipment is running at high speed, and providing real-time feedback on the equipment's motion status to the upper control system. In high-speed automated production lines, this high-speed signal transmission capability ensures real-time monitoring of conveyor belt speed, robotic arm movement position, etc., providing timely data support for precise control of the system.

2.產      品      展      示
