TOYOTA PRS-3140C定位附加板
1.產 品 資 料 介 紹：
- 輸入信號類型：支持編碼器、光電傳感器、磁性開關等位置檢測信號，可適配多種檢測設備。
- 分辨率：可達微米級（依據配置的傳感器精度），能滿足高精度定位需求。
- 接口類型：配備高速數字接口、標準工業通信端口（如 RS-422、CAN 或?qū)Ｓ每偩€），方便與其他系統連接通信。
- 響應時間：具有毫秒級實時處理能力，確保對位置變化的快速響應。
- 工作電壓：DC 5V / 12V（視設計而定），適配不同的供電環境。
- 工作環境：可在 - 10℃～+55℃溫度范圍內工作，且采用抗振動、防塵設計，能適應工業生產的復雜環境。
英文資料：
TOYOTA PRS-3140C positioning add-on board is an extended functional module specifically designed for automation control systems, with the main function of achieving high-precision positioning control and position detection. It is usually used in conjunction with the main control board or motion control system to provide accurate position data support for industrial robots, automated production lines, and precision assembly equipment. Its design goal is clear, which is to improve the repeatability accuracy and dynamic response speed of the equipment, thereby ensuring the stability and consistency of the production process.
1、 Technical parameters (example, specific values need to be confirmed according to the device version)
Input signal type: Supports position detection signals such as encoders, photoelectric sensors, magnetic switches, etc., and can be adapted to various detection devices.
Resolution: up to micrometer level (depending on the accuracy of the configured sensor), capable of meeting high-precision positioning requirements.
Interface type: Equipped with high-speed digital interfaces and standard industrial communication ports (such as RS-422, CAN, or dedicated bus) for easy connection and communication with other systems.
Response time: With millisecond level real-time processing capability, ensuring fast response to location changes.
Working voltage: DC 5V/12V (depending on the design), suitable for different power supply environments.
Working environment: It can work within the temperature range of -10 ℃ to+55 ℃, and adopts anti vibration and dust-proof design, which can adapt to the complex environment of industrial production.
2、 Application scenarios
（1） Industrial robot positioning
Suitable for precise positioning control of end effectors in articulated and Cartesian robots, it can achieve precise path execution in processes such as welding, spraying, and handling, ensuring the accuracy of robot operations.
（2） Automated assembly line
Real time detection and adjustment of workpiece position can effectively ensure assembly accuracy, reduce quality defects caused by position errors, and improve assembly quality and efficiency.
（3） Precision machining equipment
It can be applied to CNC machine tools, laser cutting, precision drilling and other equipment that require high-precision positioning, which helps improve machining consistency and dimensional accuracy, and meets the strict requirements of precision machining.
（4） Conveyor and Sorting System
Dynamic position capture can be achieved on high-speed conveyor belts, supporting automatic material sorting and fixed-point parking, improving the efficiency and accuracy of conveying and sorting.
In summary, the TOYOTA PRS-3140C positioning attachment board plays an important role in the field of automation control with its high-precision positioning control and wide applicability, providing strong guarantees for the precise operation of various equipment.
2.產 品 展 示
