AMAT Applied Materials 64-81813-00顯示PCB板

1.產 品 資 料 介 紹：

核心規格與參數

主要功能模塊

1. LVDS 信號處理：接收主控制器的 LVDS 圖像數據，進行阻抗匹配與信號整形，支持 18/24 位色深，確保高分辨率圖像無失真顯示。
2. 觸摸控制電路：采用電容式觸摸控制器，通過 USB 接口與主系統通信，支持單點或多點觸摸（依屏幕而定）。
3. 電源管理模塊：輸入 12V/24V，輸出 5V（給屏邏輯）、12V（背光），具備過壓、欠壓、短路保護功能。
4. 背光驅動電路：提供 PWM 調光接口，可調節屏幕亮度，并支持背光開啟 / 關閉控制。
5. 狀態指示與保護：設有電源、背光、觸摸狀態指示燈，方便現場維護與故障排查。

AMAT Applied Materials 64-81813-00顯示PCB板 英文資料：

AMAT 64-81813-00 is a 12.1-inch industrial touch screen display driver PCB customized for an application materials company. It is compatible with HMI operation panels for wafer manufacturing equipment such as Centura and Endura, and integrates LVDS signal processing, touch control, power management, and status indication functions. It supports a resolution of 1024 × 768 and can work stably in high-purity and strong electromagnetic interference environments in semiconductor workshops.

Core specifications and parameters

Project specifications/indicators description

Function positioning display driver+touch control+power management driver 12.1 "industrial screen and processing touch signals, integrated 5V/12V power conversion and status indication

Compatible with AMAT original screens and third-party screens that comply with VESA standards, the 12.1 "industrial touch screen (4:31024 × 768) is compatible

Interface type input: LVDS x 1, USB (touch) x 1 DC 12V/24V； Output: Backlight control signal supports single/dual channel LVDS, USB touch interface compatible with HID protocol

Material and protective substrate: FR-4; Surface treatment: Lead free hot air leveling (HASL) or chemical nickel/immersion gold (ENIG) meets IPC Class 2 industrial manufacturing standards and is suitable for workshop cleaning and maintenance environments

Size and installation: 245 × 180mm, 4 M4 mounting holes, hole spacing of 240 × 175mm, suitable for AMAT standard operation panel installation position

The working environment temperature ranges from 0 to 55 ℃; Humidity ≤ 85% RH (no condensation), anti electromagnetic interference capability in accordance with EN 61000-6-2 standard

Electrical characteristic power consumption ≤ 10W (excluding screen); LVDS impedance of 100 Ω± 10% supports 100MHz high-speed differential signal transmission, ensuring image stability

Main functional modules

LVDS signal processing: Receive LVDS image data from the main controller, perform impedance matching and signal shaping, support 18/24 bit color depth, and ensure distortion free display of high-resolution images.

Touch control circuit: Adopting a capacitive touch controller, it communicates with the main system through a USB interface and supports single or multi-point touch (depending on the screen).

Power management module: Input 12V/24V, output 5V (screen logic), 12V (backlight), with overvoltage, undervoltage, and short-circuit protection functions.

Backlight driver circuit: Provides PWM dimming interface, adjustable screen brightness, and supports backlight on/off control.

Status indication and protection: equipped with power supply, backlight, and touch status indicator lights, convenient for on-site maintenance and troubleshooting.

 AMAT Applied Materials 64-81813-00顯示PCB板 產品展示
