AMAT Applied Materials 0100-90855旋轉/掃描聯鎖板

1.產 品 資 料 介 紹：

產品概述

AMAT 0100-90855 旋轉/掃描聯鎖板是 Applied Materials 半導體設備中的安全和控制模塊，用于管理設備中旋轉部件或掃描系統的動作聯鎖。該模塊通過監控旋轉或掃描裝置的狀態，確保在設備操作或工藝運行過程中實現安全互鎖，防止設備損壞或工藝異常。它是半導體設備自動化運行和操作安全的重要組成部分。

技術參數（典型特征）

• 類型：旋轉/掃描聯鎖板 / Rotation/Scan Interlock Board

• 功能：監控旋轉或掃描系統狀態，提供安全聯鎖信號

• 輸入信號：旋轉或掃描裝置位置、速度或狀態反饋

• 輸出信號：聯鎖控制信號，傳遞至控制器或安全系統

• 接口類型：數字輸入/輸出接口，與主控制器或操作面板連接

• 工作環境：潔凈室兼容，耐高溫、抗振動

• 兼容設備：Applied Materials 各類沉積（CVD/PVD）、刻蝕（Etch）、離子注入及掃描相關工藝設備

應用場景

1. 旋轉部件聯鎖

   • 監控晶圓或工藝板旋轉裝置，確保旋轉安全運行，防止異常動作。

2. 掃描系統安全控制

   • 對掃描機構的狀態進行監控，實現操作安全互鎖。

3. 工藝保護

   • 在旋轉或掃描設備異常時自動觸發聯鎖信號，防止工藝或設備損壞。

4. 設備維護與替換

   • 模塊化設計便于拆裝和更換，減少停機時間。

AMAT Applied Materials  0100-90855旋轉/掃描聯鎖板 英文資料：

Product Overview

AMAT 0100-90855 Rotation/Scanning Interlock Board is a safety and control module in Applied Materials semiconductor equipment, used to manage the action interlocking of rotating components or scanning systems in the equipment. This module ensures safe interlocking during equipment operation or process running by monitoring the status of rotating or scanning devices, preventing equipment damage or process abnormalities. It is an important component of the automated operation and operational safety of semiconductor equipment.

Technical parameters (typical features)

Type: Rotation/Scan Interlock Board

Function: Monitor the rotation or scanning system status and provide safety interlock signals

Input signal: feedback on the position, speed, or status of the rotating or scanning device

Output signal: Interlocking control signal, transmitted to the controller or safety system

Interface type: Digital input/output interface, connected to the main controller or operation panel

Work environment: cleanroom compatible, high temperature resistant, vibration resistant

Compatible devices: Applied Materials various deposition (CVD/PVD), etching (Etch), ion implantation, and scanning related process equipment

Application scenarios

Interlocking of rotating components

Monitor the wafer or process board rotation device to ensure safe operation and prevent abnormal movements.

Scanning system security control

Monitor the status of the scanning mechanism and achieve operational safety interlock.

Process protection

Automatically trigger interlocking signals when rotating or scanning equipment is abnormal to prevent process or equipment damage.

Equipment maintenance and replacement

Modular design facilitates disassembly and replacement, reducing downtime.

AMAT Applied Materials  0100-90855旋轉/掃描聯鎖板 產品展示

 產品視頻
