AMAT 0680-01055斷路器

1.產 品 資 料 介 紹：

AMAT 0680-01055 斷路器

產品概述

AMAT（Applied Materials）0680-01055 斷路器是一種用于半導體制造設備的電氣保護裝置，主要功能是對設備的電路進行過載、短路及異常電流保護。它能夠在電流超過設定閾值時自動斷開電路，防止設備內部電氣模塊受損或引發安全事故。斷路器通常安裝在控制箱或底盤控制箱中，是保障 AMAT 設備安全運行的關鍵元件。

技術參數（典型方向，具體數據需參考原廠資料）

• 額定電流：根據設備設計規格（工業標準范圍）

• 額定電壓：適配半導體設備內部電源系統

• 動作特性：瞬時過流保護與延時過載保護

• 機械壽命：高可靠機械觸點，可承受多次操作

• 安裝方式：模塊化或插入式，便于設備集成與更換

• 環境適應性：適應高潔凈、低濕度的半導體設備環境

應用場景

1. 控制箱與底盤控制箱保護

   • 作為電源總開關和保護裝置，防止設備電氣模塊因過載或短路損壞

   • 保障氣門、加熱器、控制器、PCB 等模塊的安全運行

2. 沉積工藝（CVD/PVD/ALD）設備保護

   • 在腔體加熱器、泵浦、射頻模塊或氣體控制系統異常時切斷電源，避免工藝損壞

3. 刻蝕工藝設備保護

   • 保護射頻功率模塊、閥門和傳感器線路，防止短路或過載導致設備停機

4. 離子注入系統保護

   • 斷路器監控電源負載，確保離子源和掃描系統安全

5. 工廠安全與維護

   • 作為互鎖保護的一部分，保障操作人員和設備安全

   • 在維護或異常情況下，可快速斷開電路進行安全操作

AMAT  0680-01055斷路器 英文資料：

AMAT 0680-01055 Circuit Breaker

Product Overview

AMAT (Applied Materials) 0680-01055 circuit breaker is an electrical protection device used in semiconductor manufacturing equipment. Its main function is to protect the circuit of the equipment from overload, short circuit, and abnormal current. It can automatically disconnect the circuit when the current exceeds the set threshold, preventing damage to the internal electrical modules of the equipment or causing safety accidents. Circuit breakers are usually installed in control boxes or chassis control boxes and are key components to ensure the safe operation of AMAT equipment.

Technical parameters (typical direction, specific data should refer to the original factory information)

Rated current: According to the equipment design specifications (industrial standard range)

Rated voltage: Suitable for the internal power supply system of semiconductor equipment

Action characteristics: instantaneous overcurrent protection and delayed overload protection

Mechanical lifespan: Highly reliable mechanical contacts that can withstand multiple operations

Installation method: modular or plug-in, easy to integrate and ｒｅｐｌａｃｅ equipment

Environmental adaptability: Suitable for semiconductor equipment environments with high cleanliness and low humidity

Application scenarios

Control box and chassis control box protection

As the main power switch and protective device, it prevents damage to the electrical modules of the equipment due to overload or short circuit

Ensure the safe operation of modules such as valves, heaters, controllers, PCBs, etc

Equipment protection for sedimentation processes (CVD/PVD/ALD)

Cut off the power supply in case of abnormalities in the cavity heater, pump, RF module, or gas control system to avoid process damage

Etching process equipment protection

Protect RF power modules, valves, and sensor circuits to prevent equipment shutdown caused by short circuits or overloads

Ion implantation system protection

Circuit breakers monitor power loads to ensure the safety of ion sources and scanning systems

Factory Safety and Maintenance

As part of interlock protection, ensure the safety of operators and equipment

In maintenance or abnormal situations, the circuit can be quickly disconnected for safe operation

AMAT 0680-01055斷路器  產品展示

 產品視頻
