AMAT 0010-38838交流配電器

1.產 品 資 料 介 紹：

AMAT 0010-38838 交流配電器

產品概述

AMAT（Applied Materials）0010-38838 交流配電器是一種用于半導體制造設備的電力分配與管理模塊。它主要負責將工業交流電源合理分配至設備內部各子模塊，如控制器、加熱器、泵浦、氣動閥門和射頻模塊，確保各模塊獲得穩定、可靠的電源供應。交流配電器通常集成過載保護、短路保護及安全互鎖接口，是設備電氣系統的核心基礎設施之一。

技術參數（典型方向，具體數據需參考原廠資料）

• 輸入電源：工業標準 AC 電源

• 輸出通道：多路交流電輸出，適配各子模塊需求

• 保護功能：過載保護、短路保護、過壓保護

• 接口：與控制系統和互鎖系統連接，實現遠程監控與控制

• 安裝方式：模塊化安裝，便于集成于控制箱或底盤

• 環境適應性：適應半導體設備潔凈室和高功率工藝環境

應用場景

1. 沉積工藝（CVD/PVD/ALD）

   • 為加熱器、泵浦、氣體閥門、控制器等模塊提供穩定電源

   • 保證沉積過程的工藝穩定性和設備安全

2. 刻蝕工藝設備

   • 分配電源給射頻功率模塊、傳感器和氣動組件

   • 支持刻蝕過程的精確控制和工藝重復性

3. 離子注入系統

   • 為離子源、掃描系統及束流監測模塊供電

   • 確保注入劑量和能量的穩定性

4. 控制箱與底盤控制箱

   • 作為內部電源分配核心，提高設備電氣系統可靠性

   • 集成互鎖接口，實現過載、短路和安全保護

5. 工廠自動化與安全管理

   • 通過與上位系統連接，支持遠程監控、報警及自動停機

   • 保障設備運行安全與工藝連續性

AMAT  0010-38838交流配電器 英文資料：

AMAT 0010-38838 AC Distributor

Product Overview

AMAT (Applied Materials) 0010-38838 AC distributor is a power distribution and management module used in semiconductor manufacturing equipment. It is mainly responsible for distributing industrial AC power to various sub modules within the equipment, such as controllers, heaters, pumps, pneumatic valves, and RF modules, to ensure stable and reliable power supply for each module. Communication power distribution equipment usually integrates overload protection, short circuit protection, and safety interlock interfaces, and is one of the core infrastructure of equipment electrical systems.

Technical parameters (typical direction, specific data should refer to the original factory information)

Input power supply: Industrial standard AC power supply

Output channel: Multiple AC power outputs, adapted to the requirements of each submodule

Protection functions: overload protection, short circuit protection, overvoltage protection

Interface: Connect with the control system and interlock system to achieve remote monitoring and control

Installation method: Modular installation, easy to integrate into the control box or chassis

Environmental adaptability: Suitable for semiconductor equipment cleanrooms and high-power process environments

Application scenarios

Deposition process (CVD/PVD/ALD)

Provide stable power supply for modules such as heaters, pumps, gas valves, controllers, etc

Ensure the process stability and equipment safety during sedimentation

Etching process equipment

Allocate power to RF power modules, sensors, and pneumatic components

Support precise control and process repeatability of etching process

Ion implantation system

Power supply for ion source, scanning system, and beam monitoring module

Ensure the stability of injected dose and energy

Control box and chassis control box

As the core of internal power distribution, improving the reliability of equipment electrical systems

Integrate interlocking interfaces to achieve overload, short circuit, and safety protection

Factory Automation and Safety Management

By connecting with the upper system, it supports remote monitoring, alarm and automatic shutdown

Ensure equipment operation safety and process continuity

AMAT 0010-38838交流配電器 產品展示

 產品視頻
