AMAT 0190-18266氣動鎖緊組件

1.產 品 資 料 介 紹：

AMAT 0190-18266 氣動鎖緊組件

產品概述

AMAT（Applied Materials）0190-18266 氣動鎖緊組件是一種用于半導體制造設備的機械定位與固定模塊，通過氣動驅動實現設備部件的快速鎖緊或釋放。它通常用于固定反應腔體、工藝模塊或可移動托盤，保證工藝過程中部件的穩定性和精確定位，同時支持快速拆裝和維護。

技術參數（典型方向，具體數據需參考原廠資料）

• 驅動方式：氣動執行機構

• 鎖緊力：滿足設備部件固定所需的機械力

• 行程：根據模塊設計，可實現完全鎖緊和釋放

• 接口：氣動管路接口，兼容設備控制系統

• 安裝方式：模塊化，便于集成到設備底盤或腔體模塊

• 環境適應性：適應半導體潔凈室及高溫、真空工藝環境

應用場景

1. 沉積工藝（CVD/PVD/ALD）

   • 鎖緊腔體或工藝模塊，保證薄膜沉積過程中工藝位置精度

   • 支持快速拆裝以便設備維護或更換模塊

2. 刻蝕工藝設備

   • 固定刻蝕腔體或工藝組件，確?？涛g均勻性和工藝重復性

3. 離子注入系統

   • 鎖緊掃描系統或束流模塊，保持精確對準和穩定性

4. 設備維護與操作

   • 提供安全鎖定功能，防止移動部件意外滑動或松動

   • 支持快速釋放，便于現場維護和模塊更換

5. 自動化工藝平臺

   • 與氣動控制系統結合，實現遠程自動鎖緊和釋放，提高操作效率

AMAT  0190-18266氣動鎖緊組件 英文資料：

AMAT 0190-18266 Pneumatic Locking Component

Product Overview

AMAT (Applied Materials) 0190-1826 Pneumatic Locking Assembly is a mechanical positioning and fixing module used in semiconductor manufacturing equipment, which achieves rapid locking or releasing of equipment components through pneumatic drive. It is usually used to fix reaction chambers, process modules, or movable trays, ensuring the stability and precise positioning of components during the process, while supporting quick disassembly and maintenance.

Technical parameters (typical direction, specific data should refer to the original factory information)

Drive mode: Pneumatic actuator

Locking force: the mechanical force required to fix the equipment components

Journey: According to the module design, it can achieve complete locking and releasing

Interface: Pneumatic pipeline interface, compatible with equipment control system

Installation method: Modular, easy to integrate into equipment chassis or cavity modules

Environmental adaptability: Suitable for semiconductor cleanrooms and high-temperature, vacuum process environments

Application scenarios

Deposition process (CVD/PVD/ALD)

Lock the cavity or process module to ensure the accuracy of the process position during the thin film deposition process

Support quick disassembly and assembly for equipment maintenance or module replacement

Etching process equipment

Fixed etching chamber or process components to ensure etching uniformity and process repeatability

Ion implantation system

Lock the scanning system or beam module to maintain precise alignment and stability

Equipment maintenance and operation

Provide safety locking function to prevent accidental sliding or loosening of moving parts

Support quick release for easy on-site maintenance and module replacement

Automated process platform

Combined with pneumatic control system, achieve remote automatic locking and releasing, and improve operational efficiency

AMAT 0190-18266氣動鎖緊組件 產品展示

 產品視頻
