GE IS200FHVBG1A高壓輸入板
1.產 品 資 料 介 紹：
中文資料：
名稱
IS200FHVBG1A 高壓輸入板
產品概述
IS200FHVBG1A 是 GE 通用電氣為 LS2100 系列靜態起動系統設計的高壓輸入板 主要功能是接收控制信號 并將其轉換為門極信號以驅動可控硅 同時具備對輸入高壓的檢測保護與反饋能力 屬于系統中關鍵的高壓接口控制部件
核心功能
高壓輸入監測 監測系統中的高壓輸入電壓 保障系統在安全電壓范圍內工作
門極信號驅動 接收來自主控制系統的觸發信號 生成可靠的門極脈沖驅動 SCR 可控硅導通
狀態反饋 向上級控制板反饋電壓 電流與門極狀態 用于系統保護與閉環控制
故障指示 檢測門極故障 并通過信號接口傳輸至 FGPA 或其它主控邏輯模塊
技術參數
適配系統為 LS2100 系列
典型應用電壓等級為中壓三相交流系統
工作溫度范圍為零下四十至七十?dāng)z氏度
板卡尺寸為十六乘十二乘十六厘米
重量約為零點八千克
支持多通道門極觸發與信號反饋
具備基本防護功能 可適用于工業環境
應用場景
主要用于 GE 靜態勵磁系統中的 SCR 可控硅觸發控制
燃?xì)夂驼羝麥u輪機的起動和勵磁調節系統
大型工業電機起動和功率轉換系統
電力電子換流系統中的高壓接口與保護板
英文資料：
name
IS200FHVBG1A High Voltage Input Board
product overview
IS200FHVBG1A is a high-voltage input board designed by GE General Electric for the LS2100 series static starting system. Its main function is to receive control signals and convert them into gate signals to drive thyristors. It also has the ability to detect, protect, and feedback input high voltage, and is a key high-voltage interface control component in the system
Core functions
The high-voltage input voltage guarantee system in the high-voltage input monitoring system operates within the safe voltage range
The gate signal drives the reception of trigger signals from the main control system to generate reliable gate pulse drives for SCR thyristor conduction
Feedback the voltage, current, and gate status to the higher-level control board for system protection and closed-loop control
Fault indication detection gate pole fault and transmission to FGPA or other main control logic modules through signal interface
Technical Parameter
The adaptation system is the LS2100 series
Typical application voltage level is medium voltage three-phase AC system
The working temperature range is minus 40 to 70 degrees Celsius
The board size is sixteen by twelve by sixteen centimeters
The weight is about 0.8 kilograms
Support multi-channel gate triggering and signal feedback
Capable of basic protective functions and suitable for industrial environments
Application scenarios
Mainly used for SCR thyristor trigger control in GE static excitation system
Start up and excitation control system for gas and steam turbines
Large industrial motor starting and power conversion system
High voltage interface and protection board in power electronic converter system
