GE IS200LSGIH1A接口卡
1.產 品 資 料 介 紹：
中文資料：
IS200LSGIH1A 接口卡
產品描述
IS200LSGIH1A 是通用電氣公司 GE 為其 Mark VI 或 LS2100 控制系統開發的一款通用接口板 主要負責控制系統與外部執行部件之間的信號交互 該模塊通常作為門極脈沖信號與狀態信號的轉換橋梁 是整流系統中實現閉環控制的重要通信組件
主要功能
信號中繼 將控制器的低壓控制信號轉換為用于驅動功率部件的標準邏輯信號
門極同步 將主控板的脈沖時序同步轉發至多個功率模塊 保證多橋臂運行同步
狀態采樣 采集外部執行器或功率器件的運行狀態信號 返回給主控進行狀態判斷
通信接口 提供與系統其它部分的高速數字通信接口 具備抗干擾能力
技術參數
板卡類型 通信與控制接口板
典型應用系統 Mark VI 或 LS2100
安裝方式 插卡式模塊 安裝于控制機架內部
工作電壓 一般為直流五伏或十二伏供電
工作溫度范圍 零下二十至七十?dāng)z氏度
典型尺寸 三十厘米乘二十厘米
重約零點六千克
信號通道數量 多路隔離通道 支持多信號輸入輸出并行傳輸
連接方式 多引腳連接器 支持標準 GE 系統連接總線
應用場景
應用于 GE Mark VI 和 LS2100 控制系統中
用于控制高壓電源系統中的 SCR 門極觸發同步
可用于渦輪機控制系統 整流柜 模塊化電力系統接口
適用于電廠 發電機組 大型變頻控制系統
英文資料：
IS200LSGIH1A interface card
product description
IS200LSGIH1A is a universal interface board developed by General Electric for its Mark VI or LS2100 control system. It is mainly responsible for signal interaction between the control system and external execution components. This module is usually used as a bridge for converting gate pulse signals and status signals, and is an important communication component for achieving closed-loop control in rectification systems
major function
Signal relay converts the low-voltage control signal of the controller into a standard logic signal for driving power components
Gate synchronization forwards the pulse timing of the main control board to multiple power modules to ensure synchronous operation of multiple bridge arms
State sampling collects the operating status signals of external actuators or power devices and returns them to the main control for status judgment
The communication interface provides high-speed digital communication interfaces with anti-interference capabilities to other parts of the system
Technical Parameter
Board type communication and control interface board
Typical application system Mark VI or LS2100
Installation method: The plug-in card module is installed inside the control rack
The working voltage is generally supplied with DC five volts or twelve volts
Working temperature range: minus 20 to 70 degrees Celsius
Typical dimensions are 30 centimeters by 20 centimeters
Weighing approximately 0.6 kilograms
Number of signal channels, multiple isolated channels supporting parallel transmission of multiple signal inputs and outputs
Connection method: Multi pin connector supports standard GE system connection bus
Application scenarios
Applied to GE Mark VI and LS2100 control systems
Used to control the synchronization of SCR gate triggering in high-voltage power supply systems
Can be used for modular power system interface of rectifier cabinet in turbine control system
Suitable for large-scale variable frequency control systems of power plant generator sets
