GE IS200FGPAG1A放大器模塊
1.產 品 資 料 介 紹：
中文資料：
IS200FGPAG1A 放大器模塊
產品概述
IS200FGPAG1A 是通用電氣公司 GE 設計的一款專用于 LS2100 系列靜態起動系統的放大器模塊 主要用于驅動可控硅的門極信號 并監控其狀態 保障電力系統在起動階段的穩定運行
核心功能
一 控制門極觸發
模塊接收主控板發出的門極信號 并將其進行功率放大 用于驅動高壓可控硅器件
二 狀態反饋監測
模塊實時反饋 SCR 的導通狀態和工作電壓值 協助控制系統判斷開關狀態與故障情況
三 電源電壓轉換
將輸入電源變換為適合內部電路的低壓直流供電 用于控制和信號處理
四 系統協同控制
與 LS2100 控制平臺中的多個子板共同運行 實現完整的起動控制邏輯
技術參數
適配系統為 LS2100 和 LS2100e
工作電壓等級包括 2300V 三相 或 4160V 和 6600V 系統
支持最高六個橋臂結構同步運行
典型安裝于橋柜內部 與主控制板通過母線和信號線連接
標準工作溫度范圍為零下二十度至七十度
模塊重量約為零點九千克
模塊尺寸為六十一厘米乘五十一厘米乘五十一厘米
應用場景
適用于重型燃?xì)廨啓C(jī)靜態起動系統
高壓大功率電機驅動系統
工業電廠變頻起動控制系統
配合 SCR 驅動模塊進行邏輯控制與狀態反饋的場合
英文資料：
IS200FGPAG1A amplifier module
product overview
IS200FGPAG1A is an amplifier module designed by General Electric for the LS2100 series static starting system. It is mainly used to drive the gate signal of the thyristor and monitor its status to ensure the stable operation of the power system during the starting phase
Core functions
One control gate trigger
The module receives the gate signal from the main control board and amplifies it to drive high-voltage thyristor devices
Two state feedback monitoring
The module provides real-time feedback on the conduction status and operating voltage value of the SCR to assist the control system in determining the switch status and fault conditions
Three power supply voltage conversion
Transform the input power supply into low-voltage DC power suitable for internal circuits for control and signal processing
Four system collaborative control
Collaborate with multiple sub boards in the LS2100 control platform to achieve complete startup control logic
Technical Parameter
The compatible systems are LS2100 and LS2100e
The working voltage level includes 2300V three-phase or 4160V and 6600V systems
Supports synchronous operation of up to six bridge arm structures
Typically installed inside the bridge cabinet and connected to the main control board through busbars and signal lines
The standard operating temperature range is from minus 20 degrees Celsius to 70 degrees Celsius
The weight of the module is approximately 0.9 kilograms
The module size is 61 centimeters by 51 centimeters by 51 centimeters
Application scenarios
Suitable for heavy-duty gas turbine static starting system
High voltage and high-power motor drive system
Variable frequency starting control system for industrial power plants
In situations where logic control and status feedback are carried out in conjunction with the SCR drive module
