GE DS200FHVAG1A電源模塊
1.產 品 資 料 介 紹：
中文資料：
GE DS200FHVAG1A是一款高壓柵極接口板，主要用于GE工業控制系統中的高壓接口管理。它廣泛應用于GE Mark V靜態起動系統，用于控制SCR（可控硅）柵極驅動信號，并確保電力轉換系統的穩定性和可靠性。
主要功能：
SCR柵極控制
該模塊用于控制LCI（負載換流變流器）中的SCR橋，確保電流轉換過程中對可控硅的精確控制。高壓信號處理
能夠安全可靠地傳遞高壓信號，保障系統的穩定運行。光纖通信接口
支持通過光纖接口與主控制系統進行快速且抗干擾的通信。診斷功能
配備LED指示燈，提供各通道的工作狀態反饋，便于現場維護和故障排查。電壓監控
實時監測電池電壓，確保系統穩定運行，并具備保護功能。
技術規格：
工作溫度范圍：0°C到50°C
尺寸：約8.3厘米乘12.7厘米
電源供應：無需外部電源，通過主控制系統提供電源
安裝方式：插槽式安裝于GE控制機柜內
應用領域：
燃?xì)廨啓C(jī)和蒸汽輪機控制系統
高壓變頻驅動系統
電力廠和重工業的電源控制系統
英文資料：
GE DS200FHVAG1A is a high-voltage grid interface board mainly used for high-voltage interface management in GE industrial control systems. It is widely used in the GE Mark V static starting system to control the SCR (thyristor) gate drive signal and ensure the stability and reliability of the power conversion system.
Main functions:
SCR gate control
This module is used to control the SCR bridge in LCI (Load Converter) to ensure precise control of the thyristor during the current conversion process.
High voltage signal processing
Capable of safely and reliably transmitting high-voltage signals, ensuring the stable operation of the system.
Fiber optic communication interface
Support fast and anti-interference communication with the main control system through fiber optic interfaces.
diagnostic function
Equipped with LED indicator lights, providing feedback on the working status of each channel for easy on-site maintenance and troubleshooting.
voltage monitor
Real time monitoring of battery voltage to ensure stable system operation and protection function.
Technical specifications:
Working temperature range: 0 ° C to 50 ° C
Size: Approximately 8.3 centimeters by 12.7 centimeters
Power supply: No external power is required, power is provided through the main control system
Installation method: Slot type installation inside GE control cabinet
Application areas:
Gas turbine and steam turbine control systems
High voltage variable frequency drive system
Power control systems for power plants and heavy industries
2.產 品 展 示
