ALCATEL LUCENT  3BA53065NA印刷電路板

1.產 品 資 料 介 紹：

中文資料：

ALCATEL LUCENT 3BA53065NA 印刷電路板（又稱 Z24-2 模擬擴展板）

產品簡介：
這是一款用于 Alcatel-Lucent OmniPCX Enterprise 電話系統的擴展模塊，主要負責提供24個模擬用戶接口，適用于連接傳統模擬電話設備，如傳真機、電話機或門禁對講設備。它屬于該通信平臺的可插拔模塊之一，具備高可靠性和系統兼容性。

核心功能：

• 支持24個模擬終端接口，適配常規POTS設備

• 通過系統總線與主控板連接，實現統一管理

• 支持模擬呼叫、傳真、語音郵件等基礎功能

• 可進行遠程配置與故障診斷

• 熱插拔設計，維護與更換便捷

應用領域：

1. 企業通信系統：用于擴展辦公樓中模擬電話的部署數量。

2. 酒店通信網絡：滿足酒店房間內模擬電話連接需求。

3. 醫療行業：連接護士站、病房等位置的模擬終端設備。

4. 呼叫中心：支持大量座席使用模擬電話進行客戶溝通。

5. 教育系統：部署于學校、實驗室或辦公區域的電話通信。

英文資料：

ALCATEL LUCENT 3BA53065NA Printed Circuit Board (also known as Z24-2 Analog Expansion Board)

Product Introduction:

This is an expansion module for Alcatel Lucent OmniPCX Enterprise telephone systems, mainly responsible for providing 24 analog user interfaces, suitable for connecting traditional analog telephone devices such as fax machines, telephones, or access control intercom devices. It is one of the pluggable modules of the communication platform, with high reliability and system compatibility.

Core functions:

Supports 24 simulated terminal interfaces, compatible with conventional POS devices

Connect to the main control board through the system bus to achieve unified management

Support basic functions such as simulated calling, fax, voice mail, etc

Can perform remote configuration and fault diagnosis

Hot swappable design, easy maintenance and replacement

Application areas:

Enterprise communication system: used to expand the deployment of analog telephones in office buildings.

Hotel communication network: meets the analog telephone connection requirements in hotel rooms.

Medical industry: analog terminal devices that connect nurse stations, wards, and other locations.

Call Center: Supports a large number of agents to use analog phones for customer communication.

Education system: Telephone communication deployed in schools, laboratories, or office areas.

2.產      品      展      示
