ALCATEL LUCENT 3CM03285MK通信模塊

1.產 品 資 料 介 紹：

中文資料：

產品型號：3CM03285MK
制造商：Alcatel-Lucent（現為諾基亞 Nokia）
產品類別：通信模塊 / 接口處理模塊
用途：用于通信系統中數據交互、接口擴展、協議處理等任務

功能概述：

1. 提供設備間或系統間的通信接口，具備高速數據傳輸能力

2. 支持主控與子模塊、模塊與網絡之間的協議解析與信息交換

3. 可用于通信系統中控制鏈路或數據鏈路的建立和維護

4. 模塊具備一定的協議棧處理能力，支持SNMP、以太網、串口等接口協議（依據配置）

技術特性（典型配置）：

• 接口類型：可能包含高速以太網或串口接口

• 工作電壓：由機框或主板統一供電

• 安裝方式：插槽式熱插拔設計

• 工作溫度范圍：-5℃ 至 +55℃，適應通信機房環(huán)境

• 管理支持：可通過主設備監(jiān)控軟件或命令行接口進行管理和配置

適用設備：
適用于Alcatel-Lucent的多種核心網或接入網平臺，包括但不限于：

• 寬帶接入平臺（如ISAM系列）

• 傳輸系統設備

• 無線通信控制器等

使用注意事項：

• 安裝前應確認模塊插槽及電源匹配

• 替換需斷電或確保支持熱插拔

• 系統檢測到模塊后，應進行版本與配置匹配校驗

英文資料：

Product model: 3CM03285MK

Manufacturer: Alcatel Lucent (now Nokia)

Product category: Communication module/Interface processing module

Purpose: Used for tasks such as data exchange, interface expansion, protocol processing, etc. in communication systems

Function Overview:

Provide communication interfaces between devices or systems, with high-speed data transmission capabilities

Support protocol parsing and information exchange between the main control and sub modules, modules and networks

Can be used for establishing and maintaining control or data links in communication systems

The module has certain protocol stack processing capabilities and supports interface protocols such as SNMP, Ethernet, serial port, etc. (depending on configuration)

Technical characteristics (typical configuration):

Interface type: may include high-speed Ethernet or serial port interface

Working voltage: uniformly powered by the chassis or motherboard

Installation method: Slot style hot swappable design

Working temperature range: -5 ℃ to+55 ℃, suitable for communication room environment

Management support: can be managed and configured through the main device monitoring software or command-line interface

Applicable equipment:

Suitable for various core or access network platforms of Alcatel Lucent, including but not limited to:

Broadband access platform (such as ISAM series)

Transmission system equipment

Wireless communication controller, etc

Precautions for use:

Before installation, it is necessary to confirm that the module slot and power supply match

Replacement requires power outage or ensuring support for hot swapping

After the system detects the module, it should perform version and configuration matching verification

2.產      品      展      示
