HORNER ELECTRIC HE693THM884熱電偶輸入模塊

1.產 品 資 料 介 紹：

中文資料：

HORNER ELECTRIC HE693THM884 是一款 熱電偶輸入模塊，設計用于 GE Fanuc 90-30 PLC 系列，可用于接收和處理來自熱電偶傳感器的溫度信號。該模塊能夠精確測量各種熱電偶類型的溫度，并通過 PLC 系統進行數據處理和控制，廣泛應用于工業自動化系統中的溫度監控與過程控制。

主要特點：

1. 兼容性

   • 專為 GE Fanuc 90-30 PLC 系列設計，直接插入 PLC 機架中，確保與其他自動化設備的良好兼容性。

   • 適用于 Horner Electric 自動化系統，用于實時的溫度監控與控制。

2. 輸入通道

   • 提供 8 個獨立的熱電偶輸入通道，能夠同時處理多個熱電偶信號。

3. 支持的熱電偶類型

   • 支持 多種熱電偶類型，包括：

     • K型（鉻鎳-鋁鎳熱電偶）

     • J型（鐵-銅合金熱電偶）

     • T型（銅-銅鎳熱電偶）

     • E型（銅-合金熱電偶）

     • R型（鉑-鉑/銠熱電偶）

     • S型（鉑-鉑/銠熱電偶）

     • B型（鉑-銠熱電偶）

     • N型（鎳鉻-鎳鋁熱電偶）等

4. 溫度測量范圍

   • K型：-270°C 至 +1372°C

   • J型：-210°C 至 +1200°C

   • T型：-200°C 至 +400°C

   • E型：-200°C 至 +900°C

   • R/S型：0°C 至 +1768°C

   • B型：+400°C 至 +1820°C

   • N型：-200°C 至 +1300°C

   • 各種熱電偶的測量范圍根據不同的傳感器類型有所不同。

5. 冷端補償

   • 自動冷端補償功能，確保外部環境溫度變化不會影響熱電偶測量的準確性，保證溫度數據的可靠性。

6. 精度與分辨率

   • 精度：±0.25%

   • 分辨率：0.1°C 或更高，具體取決于熱電偶類型和測量范圍。

7. 通信與數據傳輸

   • 提供 數字化輸出，可以通過 PLC 程序 獲取溫度數據，并進行實時監控和控制。

8. LED 狀態指示

   • 模塊配有 LED 指示燈，用于顯示模塊工作狀態、信號輸入和故障警告，方便操作和維護。

英文資料：

HORNER ELECTRIC HE693THM884 is a thermocouple input module designed for the GE Fanuc 90-30 PLC series, which can be used to receive and process temperature signals from thermocouple sensors. This module can accurately measure the temperature of various types of thermocouples and process and control the data through a PLC system. It is widely used in temperature monitoring and process control in industrial automation systems.

Main features:

compatibility

Specially designed for the GE Fanuc 90-30 PLC series, it can be directly inserted into the PLC rack to ensure good compatibility with other automation equipment.

Suitable for Horner Electric automation systems for real-time temperature monitoring and control.

Channel

Provide 8 independent thermocouple input channels, capable of processing multiple thermocouple signals simultaneously.

Supported thermocouple types

Supports multiple types of thermocouples, including:

K-type (chromium nickel aluminum nickel thermocouple)

J-type (iron copper alloy thermocouple)

T-type (copper copper nickel thermocouple)

E-type (copper alloy thermocouple)

R-type (platinum platinum/rhodium thermocouple)

S-type (platinum platinum/rhodium thermocouple)

B-type (platinum rhodium thermocouple)

N-type (nickel chromium nickel aluminum thermocouple), etc

Temperature measurement range

K-type:- 270 ° C to+1372 ° C

J-type:- 210 ° C to+1200 ° C

T-shaped:- 200 ° C to+400 ° C

Type E:- 200 ° C to+900 ° C

R/S type: 0 ° C to+1768 ° C

Type B:+ 400 ° C to+1820 ° C

N-type:- 200 ° C to+1300 ° C

The measurement range of various thermocouples varies depending on the type of sensor.

Cold Junction Compensation

The automatic cold end compensation function ensures that external temperature changes do not affect the accuracy of thermocouple measurements, ensuring the reliability of temperature data.

Accuracy and Resolution

Accuracy: ± 0.25%

Resolution: 0.1 ° C or higher, depending on the thermocouple type and measurement range.

Communication and Data Transmission

Provide digital output, temperature data can be obtained through PLC program, and real-time monitoring and control can be carried out.

LED status indication

The module is equipped with LED indicator lights, which are used to display the working status, signal input, and fault warnings of the module, facilitating operation and maintenance.
