CONVERTEAM  MVRL2100/4601液體冷卻器模塊

1.產 品 資 料 介 紹：

中文資料：

MVRL2100-4601 是由 Converteam（現為 GE Energy）生產的 液體冷卻整流模塊，主要用于 MV3000 DELTA 驅動系統。該模塊的主要功能是將交流電源轉換為未經平滑處理的直流電源，為中壓驅動系統提供可靠的直流電源支持。

主要特點：

• 雙六脈沖整流器設計：每個模塊包含兩個三相六脈沖整流器，可獨立連接交流輸入，提供靈活的配置選項。

• 支持12脈沖網絡橋接：通過外部供電變壓器實現30°相移，并使用橋間變壓器連接兩個直流正輸出，可配置為12脈沖整流，降低諧波失真。

• 預充電電路：內置預充電電路，可通過限流電阻為晶體管模塊的直流鏈電容充電，確保系統安全啟動。

• 液體冷卻設計：采用液體冷卻方式，提高散熱效率，適用于高功率密度的應用場景。

• 溫度監測：配備熱敏電阻和溫控器，實時監測模塊溫度，提供過溫保護，確保系統穩定運行。

應用領域：

• 中壓驅動系統：廣泛應用于工業自動化領域，為中壓電機和驅動設備提供穩定的直流電源。

• 電力傳輸與分配：在電力系統中，用于將交流電轉換為直流電，滿足特定設備的供電需求。

• 可再生能源：在風力和水力發電系統中，用于整流和電能轉換，提高能源利用效率。

技術規格：

• 最大直流輸出電壓：1250 VDC

• 冷卻方式：液體冷卻

• 安裝方式：兼容標準 DELTA 安裝框架

英文資料：

MVRL2100-4601 is a liquid cooled rectifier module produced by Converteam (now GE Energy), mainly used for the MV3000 DELTA drive system. The main function of this module is to convert AC power into unsmoothed DC power, providing reliable DC power support for medium voltage drive systems.

Main features:

Double six pulse rectifier design: Each module contains two three-phase six pulse rectifiers that can be independently connected to AC inputs, providing flexible configuration options.

Support 12 pulse network bridging: achieve a 30 ° phase shift through an external power transformer, and connect two DC positive outputs using an inter bridge transformer. It can be configured as a 12 pulse rectifier to reduce harmonic distortion.

Pre charging circuit: Built in pre charging circuit, which can charge the DC link capacitor of the transistor module through a current limiting resistor to ensure safe system startup.

Liquid cooling design: Adopting liquid cooling method to improve heat dissipation efficiency, suitable for high power density application scenarios.

Temperature monitoring: equipped with thermistor and temperature controller, real-time monitoring of module temperature, providing over temperature protection to ensure stable system operation.

Application areas:

Medium voltage drive system: widely used in the field of industrial automation, providing stable DC power supply for medium voltage motors and drive equipment.

Power transmission and distribution: In the power system, it is used to convert alternating current into direct current to meet the power supply needs of specific equipment.

Renewable energy: used in wind and hydroelectric power systems for rectification and energy conversion to improve energy utilization efficiency.

Technical specifications:

Maximum DC output voltage: 1250 VDC

Cooling method: liquid cooling

Installation method: Compatible with standard DELTA installation framework
