AEG MODICON AS-BDAO-216離散輸出模塊
1.產 品 資 料 介 紹：
- 契合 Modicon TSX Compact 系列標準導軌，孔位與同系 PLC 控制器精準對齊，自然嵌入既有控制柜布局無需調整安裝架構。
- 超薄 12mm 機身設計，厚度優化適配高密度模塊排列，融入多 I/O 模塊堆疊場景無空間冗余，與周邊元件緊密貼合。
- 原生兼容 TSX Compact 總線協議，與 CPU 模塊即插即通，16 路離散信號輸出無需額外協議配置，自然銜接控制中樞。
- 標準 24VDC 供電設計，直接接入工業通用電源回路，自然匹配傳感器、執行器供電體系，無需專用電源模塊。
- 彈簧式接線端子設計，接線牢固且免工具拆卸，自然適配生產線快速布線與故障搶修需求。
- 16 路獨立離散輸出通道，每路支持 2A 輸出電流，與繼電器、電磁閥等 DC 負載自然匹配，無需額外功率放大設備。
- 兼容 TSX Compact 系列 legacy 系統，舊設備升級時可直接替換老舊輸出模塊，自然承接原有控制邏輯與負載配置。
- Class I Div. 2 防爆認證，適配爆炸性氣體環境，自然融入化工、油氣等危險工業場景無安全隱患。
- 輕量化 302gm 設計，重量較同通道輸出模塊降低 18%，融入高層導軌或密集安裝場景無承重壓力。
- 寬溫域穩定運行范圍覆蓋 - 20℃~65℃，自然適配高溫車間、戶外控制柜等多工況環境，性能不受溫度波動影響。
- 內置過載保護功能，負載異常時自動切斷輸出，自然保護后端執行器與模塊本身，降低故障擴散風險。
- IP20 防塵防護設計，優化外殼密封結構，自然融入粉塵較多的工業現場，延長模塊使用壽命。
- 非隔離式輸出架構，為上游隔離系統提供成本優化方案，自然適配無需通道隔離的常規控制場景。
AEG MODICON AS-BDAO-216離散輸出模塊 英文資料：
Compliant with the Modicon TSX Compact series standard guide rail, the hole positions are precisely aligned with the same PLC controller, naturally embedded in the existing control cabinet layout without the need to adjust the installation architecture.
The ultra-thin 12mm body design is optimized for high-density module arrangement, integrating multiple I/O module stacking scenarios without spatial redundancy, and closely fitting with surrounding components.
Native compatibility with TSX Compact bus protocol, plug and play with CPU module, 16 discrete signal outputs without additional protocol configuration, naturally connected to the control center.
Standard 24VDC power supply design, directly connected to industrial universal power supply circuit, naturally matched with sensor and actuator power supply system, without the need for dedicated power modules.
Spring type terminal block design ensures secure and tool free wiring, making it suitable for quick wiring and fault repair needs on production lines.
16 independent discrete output channels, each supporting 2A output current, naturally matched with DC loads such as relays and solenoid valves, without the need for additional power amplification equipment.
Compatible with TSX Compact series legacy systems, old output modules can be directly replaced when upgrading old devices, naturally taking over the original control logic and load configuration.
Class I Div. 2 explosion-proof certification, suitable for explosive gas environments, naturally integrated into hazardous industrial scenarios such as chemical and oil and gas industries without safety hazards.
Lightweight 302gm design, with a weight reduction of 18% compared to the same channel output module, integrated into high-rise guide rails or dense installation scenarios without load-bearing pressure.
The stable operating range of wide temperature range covers -20 ℃~65 ℃, naturally adapting to multiple working conditions such as high-temperature workshops and outdoor control cabinets, and the performance is not affected by temperature fluctuations.
Built in overload protection function, automatically cuts off the output when the load is abnormal, naturally protecting the backend actuator and module itself, reducing the risk of fault propagation.
IP20 dustproof protection design, optimized shell sealing structure, naturally integrates into industrial sites with high dust content, and extends the service life of the module.
Non isolated output architecture provides cost optimization solutions for upstream isolation systems, naturally adapting to conventional control scenarios that do not require channel isolation.
AEG MODICON AS-BDAO-216離散輸出模塊 產品展示
產品視頻
