TOYOTA 24240-12230-71控制卡
1.產 品 資 料 介 紹：
- 高集成化設計：整合了信號采集、邏輯處理和控制輸出功能，減少了外部的布線數量，使系統結構更簡潔，同時提高了系統運行的可靠性。
- 精準控制能力：能夠?qū)︱?qū)動電機、液壓泵和執行機構進行精確控制，確保設備實現平穩啟動、順暢行駛以及精準的操作動作，提升作業的精度和效率。
- 工業級耐用性：采用具有抗振動、耐高溫和抗電磁干擾性能的元件，可在復雜的工況環境下長期穩定運行，適應各種嚴苛的工作條件。
- 安全保護功能：內部設有過流、過壓、過熱保護以及狀態監控機制，能有效防止設備損壞，為操作過程提供堅實的安全保障。
- 模塊化維護設計：控制卡支持快速拆卸和更換，方便進行維修和保養工作，有助于縮短設備的停機時間，降低停機成本。
- 高兼容性：專門為豐田電動叉車及相關工業設備設計，保證了接口和信號通信的穩定匹配，確保系統各部分之間能夠順暢協作。
- 電動叉車驅動控制：對行駛電機的啟動、停止、加速、減速及方向切換進行控制，使叉車能夠平穩行駛，滿足不同作業場景的移動需求。
- 液壓系統管理：協調液壓泵和電磁閥的動作，實現貨叉的升降、傾斜及側移等操作，保障貨物裝卸和搬運工作的順利進行。
- 操作信號采集與處理：接收駕駛員通過手柄、踏板及按鈕發出的信號，并將這些信號轉換為執行控制指令，實現駕駛員操作意圖與設備動作的精準對接。
- 安全監控與保護：對電池、電機及傳感器的狀態進行實時監控，及時發現潛在的安全隱患并采取相應措施，提高整車運行的安全性。
- 輔助設備控制：管理燈光、蜂鳴器及顯示面板等輔助裝置，燈光為作業提供照明，蜂鳴器起到警示作用，顯示面板反饋設備狀態，從而提高操作的便利性和安全性。
- 工業自動化設備應用：可應用于自動化搬運車、堆高機及其他工業車輛，承擔集中控制與信號管理的任務，為工業自動化的高效運行提供支持。
英文資料：
Introduction to TOYOTA 24240-12230-71 Control Card
Product Overview
The TOYOTA 24240-12230-71 control card is a core electronic control module in Toyota electric forklifts and related industrial vehicles. Its main function is to receive driver operation signals, process control logic, and output commands to the drive system, hydraulic system, and auxiliary equipment to achieve coordinated control of the entire vehicle. It is a key component to ensure efficient operation of the equipment.
Product Features
Highly integrated design: integrates signal acquisition, logic processing, and control output functions, reduces the number of external wiring, makes the system structure simpler, and improves the reliability of system operation.
Precision control capability: able to accurately control the drive motor, hydraulic pump, and actuator, ensuring smooth start-up, smooth travel, and precise operation of the equipment, improving the accuracy and efficiency of the operation.
Industrial grade durability: Using components with anti vibration, high temperature resistance, and anti electromagnetic interference performance, it can operate stably for a long time in complex working environments and adapt to various harsh working conditions.
Security protection function: It is equipped with overcurrent, overvoltage, overheating protection and status monitoring mechanism internally, which can effectively prevent equipment damage and provide solid security guarantee for the operation process.
Modular maintenance design: The control card supports quick disassembly and replacement, facilitating maintenance and repair work, helping to shorten equipment downtime and reduce downtime costs.
High compatibility: specially designed for Toyota electric forklifts and related industrial equipment, ensuring stable matching of interfaces and signal communication, and ensuring smooth cooperation between various parts of the system.
Product application areas
Electric forklift drive control: controls the start, stop, acceleration, deceleration, and direction switching of the driving motor to ensure smooth operation of the forklift and meet the mobility needs of different work scenarios.
Hydraulic system management: Coordinate the actions of hydraulic pumps and solenoid valves to achieve the lifting, tilting, and lateral movement of forks, ensuring smooth loading, unloading, and handling of goods.
Operation signal acquisition and processing: Receive signals sent by the driver through the handle, pedal, and button, and convert these signals into execution control instructions to achieve precise docking between the driver's operation intention and equipment actions.
Safety monitoring and protection: Real time monitoring of the status of batteries, motors, and sensors, timely detection of potential safety hazards, and taking corresponding measures to improve the safety of vehicle operation.
Auxiliary equipment control: Manage auxiliary devices such as lights, buzzers, and display panels. Lights provide illumination for operations, buzzers serve as warnings, and display panels provide feedback on equipment status, thereby improving the convenience and safety of operations.
Application of industrial automation equipment: It can be applied to automated handling vehicles, stackers, and other industrial vehicles to undertake centralized control and signal management tasks, providing support for the efficient operation of industrial automation.
2.產 品 展 示
