Gasonics A90-020-03燈報警模塊
1.產 品 資 料 介 紹：
產品名稱
Gasonics A90-020-03 燈報警模塊
（英文：Lamp Alarm Module）
一、產品概述
Gasonics A90-020-03 是用于 Gasonics 等離子清洗設備中的 多功能燈光報警模塊，集成于設備上方或操作面板位置，用于通過不同顏色的信號燈直觀指示設備運行狀態、警報、故障或準備狀態，輔助操作員快速識別系統狀況。通常與控制系統聯動，實現自動燈光狀態控制。
二、技術參數
模塊功能：三色或四色燈光報警指示
顏色類型：
通常包含：紅色（故障）、黃色（警告）、綠色（正常運行）、藍色/白色（待機或特殊狀態）
光源類型：
LED 燈珠或工業級指示燈，壽命長、亮度高
工作電壓：
+24V DC（典型）；也有 +12V DC 或 +5V DC 版本（視具體設計）
控制方式：
接收來自主控卡或 PLC 的信號，自動控制每個燈狀態
開關量輸入或繼電器觸點控制
結構形式：
塔式或面板嵌入式燈座
集成驅動電路，帶底座安裝孔
防護等級：
IP20–IP40，適用于半導體潔凈室設備環境
接口形式：
接線端子或排線連接主控系統
英文資料：
product name
Gasonics A90-020-03 Lamp Alarm Module
Lamp Alarm Module
1、 Product Overview
Gasonics A90-020-03 is a multifunctional light alarm module used in Gasonics plasma cleaning equipment, integrated above the equipment or on the operation panel. It is used to visually indicate the equipment's operating status, alarm, fault or preparation status through different colored signal lights, assisting operators in quickly identifying system conditions. Usually linked with the control system to achieve automatic lighting status control.
2、 Technical parameters
Module function: Three color or four-color light alarm indication
Color type:
Usually includes: red (fault), yellow (warning), green (normal operation), blue/white (standby or special state)
Light source type:
LED beads or industrial grade indicator lights with long lifespan and high brightness
Working voltage:
+24V DC (typical); There are also+12V DC or+5V DC versions available (depending on the specific design)
Control method:
Receive signals from the main control card or PLC to automatically control the status of each light
Switch input or relay contact control
Structural form:
Tower or panel embedded lamp holder
Integrated driver circuit with base mounting hole
Protection level:
IP20–IP40， Suitable for semiconductor cleanroom equipment environment
Interface form:
Connect the main control system to the wiring terminal or ribbon cable
2.產 品 展 示
