Gasonics A60-002-03變壓器
1.產 品 資 料 介 紹：
產品名稱
Gasonics A60-002-03 變壓器
（英文：Transformer Module）
一、產品概述
Gasonics A60-002-03 是一款應用于 Gasonics 系列等離子清洗/灰化設備中的 工藝電源變壓器，主要用于將市電或系統供電轉換為設備內部電子模塊所需的穩定交流或直流電壓。該變壓器一般位于電源子系統中，是電流驅動、控制模塊、閥控卡、電源濾波裝置等部件的關鍵供電基礎。
二、技術參數
類型：電源隔離變壓器 / 工藝控制電源變壓器
輸入電壓：
通常為 208VAC、220VAC 或 240VAC（三相或單相，視地區/配置）
輸出電壓：
多組輸出，如 24VAC、12VAC、±15VAC、或 5VDC（二次側可供多個模塊使用）
功率等級：
典型在幾十至幾百 VA（具體依型號與用途）
絕緣等級：
工業級絕緣處理，具備過載與過溫保護功能
冷卻方式：
自然風冷或強制風冷（依據安裝環境）
封裝結構：
鐵芯封裝 / 鐵殼屏蔽結構，適應高 EMI 環境
安裝方式：
面板式或底板螺栓安裝，配有標準端子或引線接頭
認證與標準：
滿足工業設備電氣安全標準，可能具備 UL 或 CE 標識（視版本而定）
英文資料：
product name
Gasonics A60-002-03 Transformer
(English: Transformer Module)
1、 Product Overview
Gasonics A60-002-03 is a process power transformer used in Gasonics series plasma cleaning/ashing equipment, mainly used to convert mains or system power into stable AC or DC voltage required by the internal electronic modules of the equipment. This transformer is generally located in the power supply subsystem and serves as a key power supply foundation for components such as current drive, control module, valve control card, and power filtering device.
2、 Technical parameters
Type: Power Isolation Transformer/Process Control Power Transformer
Input voltage:
Usually 208VAC, 220VAC, or 240VAC (three-phase or single-phase, depending on region/configuration)
Output voltage:
Multiple outputs, such as 24VAC, 12VAC, ± 15VAC, or 5VDC (the secondary side can be used by multiple modules)
Power level:
Typically ranging from tens to hundreds of VA (depending on model and usage)
Insulation level:
Industrial grade insulation treatment with overload and over temperature protection functions
Cooling method:
Natural air cooling or forced air cooling (depending on the installation environment)
Encapsulation structure:
Iron core encapsulation/iron shell shielding structure, suitable for high EMI environments
Installation method:
Panel or base plate bolt installation, equipped with standard terminals or lead connectors
Certification and Standards:
Meets industrial equipment electrical safety standards and may have UL or CE markings (depending on version)
2.產 品 展 示
