BERGER LAHR TLC411F步進電機控制驅動器
1.產 品 資 料 介 紹：
產品名稱
BERGER LAHR TLC411F 步進電機控制驅動器
一、產品概述
TLC411F 是 BERGER LAHR（現為施耐德電氣旗下品牌）推出的一款通用型步進電機驅動器，設計用于精密運動控制系統。它可驅動兩相或混合型步進電機，廣泛用于自動化、機床控制、精密輸送、半導體設備和工業檢測系統等領域，提供精確的位置控制和高效的扭矩輸出。
二、技術參數
輸入電源：
電壓：約 115 / 230 VAC（可選）
頻率：50/60 Hz
輸出電流：
最大相電流：可調節，一般為 1A ~ 4.5A
電流控制方式：恒流PWM調制
適用電機類型：
兩相或混合式步進電機
步進控制：
支持整步、半步、微步（典型值 1/2、1/4、1/8）
步進分辨率設置靈活，可通過撥碼或軟件設置
接口類型：
輸入：脈沖（STEP）、方向（DIR）信號接口
控制邏輯：TTL/差分信號兼容
具備報警輸出、使能信號、故障診斷接口等
保護功能：
過壓、過流、過熱、短路保護
故障LED指示，便于故障排查
安裝方式：
標準DIN導軌或螺絲安裝
冷卻方式：
風冷或自然對流，視安裝環境而定
英文資料：
product name
BERGER LAHR TLC411F Stepper Motor Control Driver
1、 Product Overview
TLC411F is a universal stepper motor driver launched by BERGER LAHR (now a brand under Schneider Electric), designed for precision motion control systems. It can drive two-phase or hybrid stepper motors and is widely used in fields such as automation, machine tool control, precision conveying, semiconductor equipment, and industrial detection systems, providing precise position control and efficient torque output.
2、 Technical parameters
Input power supply:
Voltage: Approximately 115/230 VAC (optional)
Frequency: 50/60 Hz
Output current:
Maximum phase current: adjustable, generally ranging from 1A to 4.5A
Current control method: constant current PWM modulation
Applicable motor types:
Two phase or hybrid stepper motor
Step control:
Supports full step, half step, and micro step (typical values 1/2, 1/4, 1/8)
The step resolution setting is flexible and can be set through dialing or software
Interface type:
Input: Pulse (STEP), Direction (DIR) signal interface
Control logic: TTL/differential signal compatible
Equipped with alarm output, enable signal, fault diagnosis interface, etc
Protection function:
Overvoltage, overcurrent, overheating, short circuit protection
Fault LED indicator for easy troubleshooting
Installation method:
Standard DIN rail or screw installation
Cooling method:
Air cooling or natural convection, depending on the installation environment
