GE   193X531ADG01電子診斷卡

1.產 品 資 料 介 紹：

中文資料：

產品名稱：電子診斷卡

產品型號：193X531ADG01

制造商：General Electric (GE)

系列歸屬：GE 193X 控制系統模塊系列

產品簡介

193X531ADG01 是 GE 為其工業驅動和控制系統開發的一款 電子診斷功能模塊，通常用于配合 GE 直流調速驅動器、勵磁系統或其他控制面板進行運行狀態診斷與系統故障分析。其主要任務是對內部信號、電源狀態、通訊狀態等進行實時監控，幫助現場技術人員判斷系統健康狀況并定位故障點。

主要功能特點

• 系統信號診斷：實時采集多個關鍵信號點數據

• LED 狀態指示：通過板載燈光顯示各類運行狀態和報警信息

• 接口測試點：提供多個信號引出點，便于示波器或萬用表檢測

• 故障追蹤輔助：用于快速定位控制鏈中可能存在的異?；蚬收隙?/p>

• 模塊化設計：易于更換和維護，兼容 GE 193X 系列底板架構

技術參數（參考值）

應用領域

• GE 可控硅調速直流驅動系統

• 工業控制系統的調試與維護

• 工程現場的信號診斷和分析

• 電力、冶金、石化等行業自動化控制系統

英文資料：

Product Name: Electronic Diagnostic Card

Product model: 193X531ADG01

manufacturer: General Electric (GE)

Series affiliation: GE 193X Control System Module Series

Product Introduction

193X531ADG01 is an electronic diagnostic module developed by GE for its industrial drive and control systems. It is typically used in conjunction with GE DC speed control drives, excitation systems, or other control panels for operational status diagnosis and system fault analysis. Its main task is to monitor internal signals, power status, communication status, etc. in real time, helping on-site technicians determine the health status of the system and locate fault points.

Main functional features

System signal diagnosis: Real time collection of data from multiple key signal points

LED status indication: Display various operating statuses and alarm information through onboard lights

Interface testing point: Provide multiple signal output points for easy detection by oscilloscopes or multimeters

Fault tracing assistance: used to quickly locate possible anomalies or faulty segments in the control chain

Modular design: easy to ｒｅｐｌａｃｅ and maintain, compatible with GE 193X series chassis architecture

Technical parameters (reference values)

Project parameter description

Working voltage+15V/+24V DC (depending on system power supply)

Signal support type: Analog signal&Digital signal

Indicator light type LED indicates system status, faults, communication, etc

Installation method: plug-in card, compatible with GE control system rack

Working temperature range: 0 ℃~+70 ℃

Interface type standard GE plug-in gold finger interface+test lead out point

application area

GE thyristor speed control DC drive system

Debugging and maintenance of industrial control systems

Signal diagnosis and analysis on engineering sites

Automation control systems for industries such as power, metallurgy, and petrochemicals
