GE 193X532ABG02驅動控制板
1.產 品 資 料 介 紹：
中文資料：
產品名稱：驅動控制板
產品型號：193X532ABG02
制造商：General Electric (GE)
產品系列：GE 193X 系列工業控制電路板
產品概述
193X532ABG02 是一款用于 GE 工業控制系統中的 驅動控制板（Drive Control Board），通常配套使用于 GE 的直流調速器或交流變頻器等設備中，用于協調和管理功率模塊的驅動信號與控制邏輯，實現電機的精確控制與狀態調節。
核心功能
輸出驅動信號：為功率晶體管或可控硅（SCR）提供柵極或門極驅動信號
采集反饋信息：采集電壓、電流、速度等反饋量用于控制回路
實現閉環控制：支持速度控制、轉矩控制、位置控制等閉環策略
過載/過壓保護：內建基本的保護邏輯和故障檢測功能
與主控板通信：與主控制板進行數據交互，接收調節命令或狀態指令
技術參數（參考值）
| 項目 | 描述 |
|---|---|
| 工作電壓 | +15V / +24V DC |
| 控制方式 | 模擬/數字混合控制（依系統架構而定） |
| 信號接口 | 多通道輸入/輸出端子 + 板載插針接口 |
| 板卡結構 | 插卡式結構，兼容 GE 驅動系統標準機架 |
| 反饋輸入信號 | 電流、電壓、轉速（視具體系統設計而定） |
| 工作溫度范圍 | 0°C ～ +70°C |
典型應用場景
GE 直流調速系統（DC Drive Systems）
GE 可控硅橋控制系統（SCR Bridge）
工業電機驅動器主控單元
自動化電氣控制系統主板或輔助控制卡
英文資料：
Product Name: Drive Control Board
Product model: 193X532ABG02
manufacturer: General Electric (GE)
Product series: GE 193X series industrial control circuit board
product overview
193X532ABG02 is a Drive Control Board used in GE industrial control systems. It is typically used in conjunction with GE's DC speed controllers or AC frequency converters to coordinate and manage the drive signals and control logic of power modules, achieving accurate control and state adjustment of motors.
Core functions
Output driving signal: Provide gate or gate driving signals for power transistors or thyristors (SCR)
Collecting feedback information: Collecting feedback quantities such as voltage, current, speed, etc. for controlling the circuit
Implement closed-loop control: support closed-loop strategies such as speed control, torque control, position control, etc
Overload/Overvoltage Protection: Built in Basic Protection Logic and Fault Detection Function
Communication with the main control board: exchange data with the main control board, receive adjustment commands or status instructions
Technical parameters (reference values)
Project Description
Working voltage+15V/+24V DC
Control mode: analog/digital hybrid control (depending on the system architecture)
Signal interface multi-channel input/output terminal+onboard pin interface
Card structure plug-in card structure, compatible with GE drive system standard rack
Feedback input signal current, voltage, speed (depending on specific system design)
Working temperature range: 0 ° C to+70 ° C
Typical application scenarios
GE DC Drive Systems
GE SCR Bridge Control System
Industrial motor driver main control unit
Automation electrical control system motherboard or auxiliary control card
