GE 193X527ACGO1接口模塊
1.產 品 資 料 介 紹：
中文資料：
產品名稱：接口模塊（Interface Module）
產品型號：193X527ACG01
制造商：General Electric (GE)
所屬系列：GE 193X 系列 工業控制系統模塊
產品描述
GE 193X527ACG01 接口模塊是 GE 193X 控制系統中的一部分，專門設計用于信號轉換與接口的工作。它作為一個中介模塊，連接主控制系統與外部設備（如傳感器、執行器、I/O 設備），提供必要的電氣適配和信號轉換。該模塊在控制系統和外圍設備之間提供可靠的通信通道，確保信號在不同電壓、電流和信號格式之間的順利傳輸。
主要功能特性
信號轉換：將不同類型的信號（模擬或數字）進行轉換和適配，確保外部設備與控制系統的兼容性
隔離功能：內置的電氣隔離設計能夠有效防止高電壓或噪聲干擾，保護系統不受外部環境影響
輸入輸出接口：支持多路輸入和輸出接口，包括模擬信號輸入輸出、數字信號輸入輸出等
高抗干擾能力：具有強大的抗電磁干擾（EMI）和電氣噪聲抑制能力，保障系統穩定性
靈活安裝：模塊采用插卡式設計，便于與 GE 193X 系列的其他組件進行快速安裝和替換
技術規格參數
| 參數名稱 | 參數說明 |
|---|---|
| 接口類型 | 模擬信號、數字信號輸入/輸出 |
| 輸入通道數 | 8 路模擬輸入，8 路數字輸入（標準配置） |
| 輸出通道數 | 8 路模擬輸出，8 路數字輸出（標準配置） |
| 輸入電壓范圍 | 5V、12V、24V DC（支持多種工業設備） |
| 輸出電壓范圍 | 5V、12V、24V DC（適配連接設備需求） |
| 信號隔離方式 | 內置電氣隔離設計，減少干擾與噪聲影響 |
| 工作溫度范圍 | 0°C 至 70°C |
| 電流承載能力 | 每通道最大 50mA（數字接口） |
| 冷卻方式 | 自然對流冷卻 |
| 安裝方式 | 插卡式設計，標準金手指接口 |
英文資料：
Product Name: Interface Module
Product model: 193X527ACG01
manufacturer: General Electric (GE)
Series: GE 193X Series Industrial Control System Module
product description
The GE 193X527ACG01 interface module is a part of the GE 193X control system, specifically designed for signal conversion and interface operations. It serves as an intermediary module that connects the main control system with external devices such as sensors, actuators, and I/O devices, providing necessary electrical adaptation and signal conversion. This module provides a reliable communication channel between the control system and peripheral devices, ensuring smooth transmission of signals between different voltages, currents, and signal formats.
Main functional features
Signal conversion: Convert and adapt different types of signals (analog or digital) to ensure compatibility between external devices and control systems
Isolation function: The built-in electrical isolation design can effectively prevent high voltage or noise interference, protecting the system from external environmental influences
Input/output interface: supports multiple input and output interfaces, including analog signal input/output, digital signal input/output, etc
High anti-interference ability: It has strong resistance to electromagnetic interference (EMI) and electrical noise suppression, ensuring system stability
Flexible installation: The module adopts a plug-in card design, which facilitates quick installation and replacement with other components of the GE 193X series
Technical specifications and parameters
Parameter Name Parameter Description
Interface type: Analog signal, digital signal input/output
8 analog inputs and 8 digital inputs (standard configuration)
Number of output channels: 8 analog outputs, 8 digital outputs (standard configuration)
Input voltage range 5V, 12V, 24V DC (supports various industrial equipment)
Output voltage range 5V, 12V, 24V DC (adapted to connect device requirements)
The signal isolation method is designed with built-in electrical isolation to reduce interference and noise effects
Working temperature range: 0 ° C to 70 ° C
Current carrying capacity: maximum 50mA per channel (digital interface)
Cooling method: natural convection cooling
Installation method: card insertion design, standard gold finger interface
2.產 品 展 示
