AMAT Applied Materials 0010-42744射頻匹配器

1.產 品 資 料 介 紹：

核心功能

• 自動調諧：內置伺服電機驅動可變電容和電感，實時跟蹤負載阻抗變化
• 反射功率抑制：通過定向耦合器和相位 / 幅度檢測，閉環調節使反射功率最小化
• 功率范圍：典型支持 0–1000W 射頻功率，適配多種工藝設備
• 頻率特性：固定工作于 13.56MHz（工業標準等離子體激發頻率）
• 通信接口：提供 RS-485、Ethernet 或?qū)Ｓ每偩€，支持與上位機 / 控制器集成

技術特點

典型應用

• 刻蝕設備：射頻耦合腔、極板匹配
• PECVD 沉積設備：反應腔阻抗匹配
• 濺射設備：靶材射頻功率高效傳輸
• 離子注入機：射頻源與匹配網絡優化

AMAT Applied Materials 0010-42744射頻匹配器 英文資料：

AMAT Applied Materials 0010-42744 is an automatic RF matching device used to dynamically match the impedance of RF power sources and loads (such as reaction chambers and plasma sources) in semiconductor manufacturing equipment, achieving efficient power transmission in the 13.56MHz frequency band and reducing reflected power.

core functionality

Automatic tuning: Built in servo motor drives variable capacitors and inductors, real-time tracking of load impedance changes

Reflection power suppression: By using directional couplers and phase/amplitude detection, closed-loop adjustment minimizes the reflection power

Power range: Typical support for 0-1000W RF power, compatible with various process equipment

Frequency characteristics: Fixed operating at 13.56MHz (industrial standard plasma excitation frequency)

Communication interface: Provides RS-485, Ethernet or dedicated bus, supports integration with upper computer/controller

Technical Features

Project parameters/characteristics

Frequency 13.56MHz (fixed)

Power capacity 0-1000W (typical value)

Matching range 5-500 Ω (adjustable)

Typical tuning time<100ms (full range)

Interface form: N-type or SMA RF interface

Protection functions include over power, over reflection, and over heat protection

Mechanical specification standard 19 "rack or chassis installation

Typical Applications

Etching equipment: RF coupling cavity, electrode matching

PECVD deposition equipment: impedance matching of reaction chamber

Sputtering equipment: efficient transmission of target RF power

Ion implantation machine: RF source and matching network optimization
