AMAT Applied Materials 0190-24116分析輸入輸出模塊

1.產 品 資 料 介 紹：

產品概述

AMAT 0190-24116 分析輸入輸出模塊是 Applied Materials 半導體設備中的關鍵信號接口模塊。它用于采集、處理和輸出設備傳感器及工藝監控信號，實現工藝參數的精確監控和控制。該模塊可連接溫度傳感器、壓力傳感器、流量計等多種監測裝置，將信號傳輸至主控制器或數字控制系統，為半導體工藝提供實時數據反饋和控制依據。

技術參數（典型特征）

• 類型：分析輸入/輸出模塊（I/O Module）

• 功能：信號采集、信號輸出、數據傳輸

• 信號類型：模擬量（如電壓、電流）及數字量輸入輸出

• 通道數量：多通道設計，可同時處理多路輸入輸出（具體數量依設備而定）

• 接口形式：標準模塊化插槽接口，兼容控制系統總線

• 工作環境：半導體設備內部，耐高溫、抗干擾、潔凈室兼容

• 適用設備：Applied Materials 各類沉積（CVD/PVD）、刻蝕（Etch）、離子注入、熱處理設備

應用場景

1. 工藝數據采集

   • 采集溫度、壓力、流量、液位等傳感器數據，提供實時反饋。

2. 控制信號輸出

   • 向閥門、加熱器、泵、執行器等子系統輸出控制指令。

3. 設備監控與報警

   • 監測工藝參數異常并向控制器發送信號，實現報警和保護。

4. 工藝優化與追溯

   • 提供精確的輸入輸出數據，為工藝優化和質量追溯提供依據。

AMAT Applied Materials 0190-24116分析輸入輸出模塊 英文資料：

Product Overview

AMAT 0190-24116 Analysis Input/Output Module is a key signal interface module in Applied Materials semiconductor equipment. It is used to collect, process, and output device sensors and process monitoring signals, achieving precise monitoring and control of process parameters. This module can connect various monitoring devices such as temperature sensors, pressure sensors, flow meters, etc., and transmit signals to the main controller or digital control system, providing real-time data feedback and control basis for semiconductor processes.

Technical parameters (typical features)

Type: Analysis Input/Output Module (I/O Module)

Function: Signal acquisition, signal output, data transmission

Signal types: analog (such as voltage, current) and digital input/output

Number of channels: Multi channel design, capable of processing multiple inputs and outputs simultaneously (the specific number depends on the device)

Interface form: Standard modular slot interface, compatible with control system bus

Working environment: Inside semiconductor equipment, high temperature resistance, anti-interference, and cleanroom compatibility

Applicable equipment: Various deposition (CVD/PVD), etching (Etch), ion implantation, and heat treatment equipment of Applied Materials

Application scenarios

Process data collection

Collect sensor data such as temperature, pressure, flow rate, and liquid level, and provide real-time feedback.

Control signal output

Output control commands to subsystems such as valves, heaters, pumps, and actuators.

Equipment monitoring and alarm

Monitor abnormal process parameters and send signals to the controller to achieve alarm and protection.

Process optimization and traceability

Provide accurate input and output data to provide a basis for process optimization and quality traceability.

AMAT Applied Materials 0190-24116分析輸入輸出模塊  產品展示

 產品視頻
