GE   193X244ACG01信號探測器

1.產 品 資 料 介 紹：

中文資料：

193X244ACG01 信號探測器
（GE General Electric 193X 系列模擬信號處理板卡）

產品概述

193X244ACG01 是 GE（通用電氣）推出的 193X 系列控制系統模塊中的一種模擬信號探測與處理板卡。它廣泛應用于工業自動化、發電廠控制系統等場合，主要用于采集、放大與處理低電平模擬信號，并將其傳輸至主控制系統，實現信號監測與控制響應。

主要功能

• 信號探測與采樣：能夠精準捕捉來自傳感器或現場設備的微弱電壓、電流信號。

• 濾波與放大：對模擬信號進行低噪聲放大，并去除雜波，提高信號質量。

• 隔離保護：內置隔離通道，保護主系統免受高壓或干擾信號沖擊。

• 信號調理：支持信號線性化、偏置校準與動態范圍調整。

技術規格

• 電源要求：±15V DC（由主控系統供電）

• 輸入信號類型：低電壓模擬信號（05V、±10V）、小電流信號（420mA）

• 輸出信號：調理后的標準模擬信號或電壓比例信號

• 信號帶寬：0～10kHz（典型）

• 信號精度：±0.1% F.S.

• 工作溫度范圍：-20°C ~ +70°C

• 結構類型：插卡式電路板，適配 GE 193X 控制架

應用場景

• 汽輪機與發電機控制系統

• 工業傳感器接口模塊

• 過程控制與反饋系統

• 信號監控與報警系統

• 隔離式數據采集前端

英文資料：

193X244ACG01 signal detector

(GE General Electric 193X Series Analog Signal Processing Board)

product overview

193X244ACG01 is an analog signal detection and processing board in the 193X series control system module launched by GE (General Electric). It is widely used in industrial automation, power plant control systems, and other applications, mainly for collecting, amplifying, and processing low-level analog signals, and transmitting them to the main control system to achieve signal monitoring and control response.

major function

Signal detection and sampling: capable of accurately capturing weak voltage and current signals from sensors or field devices.

Filtering and amplification: Low noise amplification is applied to analog signals to remove clutter and improve signal quality.

Isolation protection: Built in isolation channel to protect the main system from high voltage or interference signal impact.

Signal conditioning: supports signal linearization, bias calibration, and dynamic range adjustment.

technical specifications

Power requirement: ± 15V DC (powered by the main control system)

Input signal type: low voltage analog signal (05V, ± 10V), low current signal (420mA)

Output signal: Standard analog signal or voltage proportional signal after conditioning

Signal bandwidth: 0-10kHz (typical)

Signal accuracy: ± 0.1% F.S

Working temperature range:- 20°C ~ +70°C

Structure type: plug-in circuit board, compatible with GE 193X control rack

Application scenarios

Steam turbine and generator control system

Industrial sensor interface module

Process Control and Feedback System

Signal monitoring and alarm system

Isolation based data collection front-end
