ALCATEL LUCENT 3AL86615AJAE控制器模塊
1.產 品 資 料 介 紹：
中文資料：
ALCATEL-LUCENT 3AL86615AJAE 控制器模塊 是一款用于電信網絡核心或接入平臺中的高性能控制模塊，主要負責系統的集中控制、資源調度、配置管理和通信協調，是設備中的“大腦”核心部件之一。
一、產品基礎信息
| 項目 | 內容 |
|---|---|
| 產品型號 | 3AL86615AJAE |
| 產品名稱 | 控制器模塊 / 控制板 / 控制處理單元 |
| 品牌 | Alcatel-Lucent（現為諾基亞網絡的一部分） |
| 應用類別 | 網絡控制平臺、接入系統、傳輸節點設備等 |
二、核心功能概述
該模塊主要作為系統的主控單元（Main Controller Unit），具備以下功能：
| 功能類型 | 描述 |
|---|---|
| 集中控制 | 管理整機設備運行狀態、調度各個功能模塊、執行系統配置 |
| 協議處理 | 執行通信協議棧，如信令、數據控制、會話協議等 |
| 設備管理 | 負責系統自檢、初始化、故障監控、軟件升級等管理功能 |
| 接口調度 | 協調與接口模塊、用戶側板卡、傳輸模塊的數據交互 |
| 系統同步 | 保證系統時鐘同步、信令一致性與狀態協調 |
英文資料：
The ALCATEL-LUCENT 3AL86615AJAE controller module is a high-performance control module used in telecommunications network cores or access platforms. It is mainly responsible for centralized control, resource scheduling, configuration management, and communication coordination of the system, and is one of the core components of the "brain" in devices.
1、 Product basic information
Project Content
Product model 3AL86615AJAE
Product Name: Controller Module/Control Board/Control Processing Unit
Brand Alcatel Lucent (now part of Nokia Networks)
Application categories: Network control platform, access system, transmission node equipment, etc
2、 Overview of Core Functions
This module mainly serves as the main controller unit of the system and has the following functions:
Function type description
Centralized control and management of the overall equipment operation status, scheduling of various functional modules, and execution of system configuration
Protocol processing executes communication protocol stacks, such as signaling, data control, session protocols, etc
Equipment management is responsible for system self checking, initialization, fault monitoring, software upgrades, and other management functions
Interface scheduling coordination and data exchange between interface modules, user side panel cards, and transmission modules
System synchronization ensures system clock synchronization, signaling consistency, and state coordination
2.產 品 展 示
