HORNER ELECTRIC HE693ADC816D分析輸入模塊
1.產 品 資 料 介 紹：
中文資料：
HORNER ELECTRIC HE693ADC816D 是一款高性能的 模擬輸入模塊，專為 GE Fanuc 90-30 PLC 系列設計。該模塊支持多通道的模擬信號輸入，并能夠執行精確的信號采集與分析，廣泛應用于需要高精度數據采集的工業自動化系統中。
主要特點：
兼容性與集成
專為 GE Fanuc 90-30 PLC 系列設計，并可與 Horner Electric 的其他控制產品兼容。
可通過 Proficy Machine Edition 或 Logicmaster 90 軟件進行配置和編程，確保與現有自動化系統的無縫集成。
輸入通道
提供 16 個獨立的模擬輸入通道，每個通道支持 差分輸入 或 單端輸入，適用于各種模擬信號采集場景。
每個輸入通道都能夠處理多種類型的模擬信號，如電壓、毫伏、毫安等。
高精度與高分辨率
分辨率：16 位分辨率，能夠精確地捕獲細微的模擬信號變化。
精度：±0.1% 或更高，確保采集到的數據非常精確，適用于要求高精度的控制系統。
輸入信號類型
支持 電壓輸入（0-10V、±10V等）和 電流輸入（4-20mA等），使得該模塊能夠滿足不同類型信號的輸入需求。
支持 差分輸入模式，能夠有效抑制電氣噪聲，提供更加穩定的信號采集。
采樣與更新速率
支持 高采樣率，能夠快速采集數據并實時傳輸至 PLC 系統。
可根據需求配置不同的更新頻率，確保實時數據的獲取與處理。
輸入通道配置與靈活性
每個通道支持獨立配置，用戶可選擇差分或單端模式，并根據需要配置不同的輸入范圍。
支持自定義輸入標定，能夠滿足特定設備或傳感器的要求。
狀態指示與報警功能
配備 LED 指示燈，顯示模塊狀態，包括輸入信號的狀態、模塊工作情況以及故障警告。
提供 報警功能，當輸入信號超出設定的閾值時，會發出警告，便于及時采取措施。
擴展性與兼容性
可通過 Horner Electric 系列的 I/O 擴展模塊，進一步擴展輸入通道數，滿足大規模自動化系統的需求。
與其他 Horner Electric 自動化控制設備兼容，可以形成高效、靈活的自動化控制系統。
英文資料：
HORNER ELECTRIC HE693ADC816D is a high-performance analog input module designed specifically for the GE Fanuc 90-30 PLC series. This module supports multi-channel analog signal input and can perform precise signal acquisition and analysis, widely used in industrial automation systems that require high-precision data acquisition.
Main features:
Compatibility and Integration
Specially designed for the GE Fanuc 90-30 PLC series and compatible with other control products from Horner Electric.
It can be configured and programmed through Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing automation systems.
Channel
Provide 16 independent analog input channels, each supporting differential input or single ended input, suitable for various analog signal acquisition scenarios.
Each input channel can handle multiple types of analog signals, such as voltage, millivolts, milliamps, etc.
High precision and high resolution
Resolution: 16 bit resolution, capable of accurately capturing subtle analog signal changes.
Accuracy: ± 0.1% or higher, ensuring that the collected data is very accurate, suitable for control systems that require high precision.
Input Signal Type
Supports voltage input (0-10V, ± 10V, etc.) and current input (4-20mA, etc.), enabling the module to meet the input requirements of different types of signals.
Supporting differential input mode, it can effectively suppress electrical noise and provide more stable signal acquisition.
Sampling and ｕｐｄａｔｅ rate
Support high sampling rate, able to quickly collect data and transmit it in real-time to the PLC system.
Different ｕｐｄａｔｅ frequencies can be configured according to requirements to ensure real-time data acquisition and processing.
Input channel configuration and flexibility
Each channel supports independent configuration, and users can choose differential or single ended mode, and configure different input ranges as needed.
Support custom input calibration to meet the requirements of specific devices or sensors.
Status indication and alarm function
Equipped with LED indicator lights to display module status, including input signal status, module operation status, and fault warnings.
Provide alarm function, which will issue a warning when the input signal exceeds the set threshold, facilitating timely action.
Scalability and compatibility
The Horner Electric series of I/O expansion modules can further expand the number of input channels to meet the needs of large-scale automation systems.
Compatible with other Horner Electric automation control equipment, it can form an efficient and flexible automation control system.
2.產 品 展 示
