HORNER ELECTRIC HE693THM884J邏輯控制器

1.產 品 資 料 介 紹：

中文資料：

HORNER ELECTRIC HE693THM884J 是一款 熱電偶輸入模塊，設計用于 GE Fanuc 90-30 PLC 系列。它專門用于接收來自熱電偶傳感器的溫度信號，并將其轉換為數字信號供 PLC 進行處理。該模塊廣泛應用于溫度監測和過程控制系統，特別適用于需要高精度溫度測量的工業自動化應用。

主要特點：

1. 兼容性

   • 該模塊專為 GE Fanuc 90-30 PLC 系列設計，并且能與其他 Horner Electric 系列設備兼容。

   • 支持 Proficy Machine Edition 或 Logicmaster 90 軟件進行配置和編程，確保與現有 PLC 系統無縫集成。

2. 輸入通道

   • 提供 8 個獨立的熱電偶輸入通道，能夠同時接收多個熱電偶傳感器的信號。

   • 每個輸入通道都支持 熱電偶的多種類型，包括 K型、J型、T型、E型、R型、S型、B型和 N型等。

3. 廣泛的熱電偶類型支持

   • 支持 K型、J型、T型、E型、R型、S型、B型、N型 等多種熱電偶類型。

   • 允許用戶選擇適合自己應用的熱電偶類型，靈活應用于不同的溫度范圍和精度要求。

4. 溫度測量范圍

   • 支持各類熱電偶的溫度測量范圍：

     • K型：-270°C 至 +1372°C

     • J型：-210°C 至 +1200°C

     • T型：-200°C 至 +400°C

     • E型：-200°C 至 +900°C

     • R/S型：0°C 至 +1768°C

     • B型：+400°C 至 +1820°C

     • N型：-200°C 至 +1300°C

   • 各種熱電偶的測量范圍根據不同的型號有所不同，適應多種工業環境。

5. 冷端補償功能

   • 配備 自動冷端補償功能，確保測量過程中冷端溫度變化不會影響熱電偶的信號精度，從而保證溫度數據的準確性和可靠性。

6. 高精度與分辨率

   • 精度：±0.25%

   • 分辨率：根據熱電偶類型，分辨率可達到 0.1°C 或更高。

7. 實時數據采集與處理

   • 支持 數字化輸出，將溫度數據實時傳輸至PLC系統，供控制系統進一步處理和決策。

   • 可通過 PLC 程序讀取和使用溫度數據進行控制。

8. 狀態指示與報警功能

   • 配備 LED 指示燈，顯示模塊狀態、輸入信號及故障警告，便于操作員實時監控設備運行狀態。

   • 提供 報警功能，用于提示設備故障或溫度異常。

英文資料：

HORNER ELECTRIC HE693THM884J is a thermocouple input module designed for the GE Fanuc 90-30 PLC series. It is specifically designed to receive temperature signals from thermocouple sensors and convert them into digital signals for PLC processing. This module is widely used in temperature monitoring and process control systems, especially for industrial automation applications that require high-precision temperature measurement.

Main features:

compatibility

This module is designed specifically for the GE Fanuc 90-30 PLC series and is compatible with other Horner Electric series devices.

Support configuration and programming with Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing PLC systems.

Channel

Provide 8 independent thermocouple input channels that can simultaneously receive signals from multiple thermocouple sensors.

Each input channel supports multiple types of thermocouples, including K-type, J-type, T-type, E-type, R-type, S-type, B-type, and N-type.

Wide range of thermocouple types supported

Supports multiple thermocouple types such as K, J, T, E, R, S, B, N, etc.

Allow users to choose the appropriate thermocouple type for their application, flexibly applying it to different temperature ranges and accuracy requirements.

Temperature measurement range

Support temperature measurement range of various thermocouples:

K-type:- 270 ° C to+1372 ° C

J-type:- 210 ° C to+1200 ° C

T-shaped:- 200 ° C to+400 ° C

Type E:- 200 ° C to+900 ° C

R/S type: 0 ° C to+1768 ° C

Type B:+ 400 ° C to+1820 ° C

N-type:- 200 ° C to+1300 ° C

The measurement range of various thermocouples varies according to different models and is suitable for various industrial environments.

Cold end compensation function

Equipped with automatic cold junction compensation function to ensure that temperature changes at the cold junction during the measurement process do not affect the signal accuracy of the thermocouple, thereby ensuring the accuracy and reliability of temperature data.

High precision and resolution

Accuracy: ± 0.25%

Resolution: Depending on the type of thermocouple, the resolution can reach 0.1 ° C or higher.

Real time data collection and processing

Support digital output, real-time transmission of temperature data to PLC system for further processing and decision-making by the control system.

Temperature data can be read and controlled through PLC programs.

Status indication and alarm function

Equipped with LED indicator lights to display module status, input signals, and fault warnings, facilitating real-time monitoring of equipment operation status by operators.

Provide alarm function to indicate equipment malfunction or abnormal temperature.

2.產      品      展      示
