AMAT  0100-38027探測器板組件

1.產 品 資 料 介 紹：

AMAT 0100-38027 探測器板組件

產品概述

AMAT（Applied Materials）0100-38027 探測器板組件是一種安裝在半導體制造設備中的電子功能模塊，主要用于信號檢測、工藝監控和數據采集。它通常作為探測器與主控制系統之間的接口電路，負責接收、放大、濾波和處理來自傳感器或探頭的信號，以便實現對工藝環境和運行狀態的實時監控。該組件在沉積、刻蝕、離子注入等工藝中都可能作為關鍵監測環節。

技術參數（典型方向，具體參數需參考原廠資料）

• 電路結構：多層印刷電路板，集成探測電路與信號處理模塊

• 信號類型：支持模擬與數字信號輸入，具備高速采樣能力

• 功能特性：信號放大、噪聲抑制、數據轉換與傳輸

• 工作環境：適應半導體設備高真空、低顆粒及高潔凈度環境

• 接口：兼容 AMAT 設備主控制器和上位機系統

應用場景

1. 薄膜沉積工藝（CVD/PVD/ALD）

   • 檢測沉積過程中反應氣體或腔體環境變化，輔助閉環控制。

   • 采集等離子體發光或反射信號，用于膜厚監控。

2. 刻蝕工藝

   • 監控等離子體狀態、發射光譜或反應副產物信號。

   • 幫助實現刻蝕終點檢測（End Point Detection, EPD）。

3. 離子注入系統

   • 檢測離子束流強度或分布，保證注入劑量和均勻性。

4. 真空腔體狀態檢測

   • 與傳感器配合，實時監控腔體內壓力、氣體流量和溫度信號。

5. 工廠自動化與安全

   • 作為工藝檢測與報警觸發的前端電路，保障工藝穩定與設備安全。

AMAT 0100-38027探測器板組件 英文資料：

AMAT 0100-38027 Detector Board Component

Product Overview

AMAT (Applied Materials) 0100-38027 detector board assembly is an electronic functional module installed in semiconductor manufacturing equipment, mainly used for signal detection, process monitoring, and data acquisition. It usually serves as an interface circuit between the detector and the main control system, responsible for receiving, amplifying, filtering, and processing signals from sensors or probes to achieve real-time monitoring of the process environment and operating status. This component may serve as a key monitoring link in processes such as deposition, etching, and ion implantation.

Technical parameters (typical direction, specific parameters need to refer to the original factory information)

Circuit structure: multi-layer printed circuit board, integrated detection circuit and signal processing module

Signal type: Supports analog and digital signal input, with high-speed sampling capability

Functional features: signal amplification, noise suppression, data conversion and transmission

Work environment: Suitable for high vacuum, low particle, and high cleanliness environments of semiconductor equipment

Interface: Compatible with AMAT device main controller and upper computer system

Application scenarios

Thin film deposition process (CVD/PVD/ALD)

Detecting changes in reaction gases or chamber environment during the sedimentation process to assist in closed-loop control.

Collect plasma luminescence or reflection signals for film thickness monitoring.

etching process

Monitor plasma state, emission spectra, or reaction byproduct signals.

Assist in achieving End Point Detection (EPD) for etching.

Ion implantation system

Detect ion beam intensity or distribution to ensure injection dose and uniformity.

Vacuum chamber status detection

Cooperate with sensors to monitor real-time pressure, gas flow rate, and temperature signals inside the chamber.

Factory Automation and Safety

As a front-end circuit for process detection and alarm triggering, it ensures process stability and equipment safety.

AMAT 0100-38027探測器板組件 產品展示

 產品視頻
