GE   193X701ARG01判斷器模塊

1.產 品 資 料 介 紹：

中文資料：

GE 193X701ARG01 判斷器模塊 技術說明

產品型號：193X701ARG01
產品名稱：判斷器模塊（Discriminator Module）
產品系列：GE 193X 系列控制板
制造廠商：General Electric (GE)

產品概述

GE 193X701ARG01 是一款高精度判斷器模塊，主要用于工業控制系統中對模擬或數字輸入信號的判斷、選擇及邏輯決策。它常作為信號處理鏈中的關鍵環節，應用于狀態識別、門限判斷、控制條件設定等功能，在 GE Mark 系列控制系統中廣泛使用。

核心功能

• 信號判別：接收多個輸入信號，根據預設門限或邏輯條件進行狀態判斷；

• 輸出控制信號：當滿足特定判斷條件時，輸出相應的高/低電平或開關控制信號；

• 邏輯控制輔助：為后級繼電器模塊、控制板等提供有效的觸發依據；

• 響應時間快：適用于快速響應控制系統，反應時間小于1ms；

• 抗干擾能力強：具備良好的抗電磁干擾和信號濾波能力，適用于復雜工業環境。

技術參數

• 工作電壓：±15V DC（來自系統電源模塊）

• 輸入信號類型：模擬電壓/電流信號或 TTL 數字信號（依據配置）

• 輸出信號類型：TTL、開關量、高/低電平

• 安裝方式：標準 193X 插槽安裝，金手指邊緣連接器

• 響應速度：<1ms

• 工作溫度范圍：-20°C ~ +60°C

• 板卡尺寸：符合 GE 193X 機架尺寸規格

應用場景

• 狀態檢測與識別：電壓、電流、速度或位置信號的門限判斷

• 邏輯決策與切換：在多信號輸入情況下實現優先級控制

• 驅動系統控制輔助：與速度控制、電流調節、制動模塊配合使用

• 工業自動化流程判斷：實現順序控制、開關判斷、保護觸發等邏輯控制功能

• GE Mark 系列控制系統中的判別模塊

英文資料：

Technical Description of GE 193X701ARG01 Judgment Module

Product model: 193X701ARG01

Product Name: Discreinator Module

Product series: GE 193X series control board

Manufacturer: General Electric (GE)

product overview

GE 193X701ARG01 is a high-precision discriminator module mainly used for judging, selecting, and making logical decisions on analog or digital input signals in industrial control systems. It is often used as a key link in the signal processing chain for functions such as state recognition, threshold judgment, and control condition setting, and is widely used in GE Mark series control systems.

Core functions

Signal discrimination: Receive multiple input signals and make state judgments based on preset thresholds or logical conditions;

Output control signal: When specific judgment conditions are met, output the corresponding high/low level or switch control signal;

Logic control assistance: provides effective triggering basis for subsequent relay modules, control boards, etc;

Fast response time: suitable for fast response control systems, with a response time of less than 1ms;

Strong anti-interference ability: It has good anti-interference and signal filtering capabilities, suitable for complex industrial environments.

Technical Parameter

Working voltage: ± 15V DC (from the system power module)

Input signal type: Analog voltage/current signal or TTL digital signal (depending on configuration)

Output signal type: TTL, switch quantity, high/low level

Installation method: Standard 193X slot installation, gold finger edge connector

Response speed:<1ms

Working temperature range: -20 ° C~+60 ° C

Board size: Complies with GE 193X rack size specifications

Application scenarios

State detection and recognition: threshold judgment of voltage, current, speed or position signals

Logical decision-making and switching: implementing priority control in the case of multiple signal inputs

Drive system control assistance: used in conjunction with speed control, current regulation, and braking modules

Industrial automation process judgment: Implement logical control functions such as sequential control, switch judgment, and protection triggering

Discrimination module in GE Mark series control system
