GE   193X644AAG02直流電機驅動板

1.產 品 資 料 介 紹：

中文資料：

GE 193X644AAG02 直流電機驅動板 技術說明

產品型號：193X644AAG02
產品名稱：直流電機驅動板（DC Motor Drive Board）
所屬系列：GE 193X 系列工業控制模塊
制造廠商：General Electric (GE)

產品概述

GE 193X644AAG02 是一款專為控制直流電機驅動系統而設計的模塊化驅動板，廣泛應用于工業自動化設備、電力控制系統及機電一體化裝置。該板卡具有高可靠性、高響應速度與精密調速能力，適用于對電機啟動、調速、制動及正反轉控制有高要求的場合。

技術參數

• 電源電壓：24V DC 或 ±15V（依據系統配置）

• 驅動電流：支持控制功率范圍 0.5kW～10kW 的直流電機

• 控制方式：PWM 控制 / 模擬信號控制

• 響應時間：<1ms

• 信號接口：標準 193X 金手指邊緣連接器

• 冷卻方式：自然風冷 / 系統冷卻

核心功能

• 直流電機驅動控制：實現精確的電壓、電流調節，控制電機啟停、調速與轉向；

• 速度與電流閉環控制：可接收測速信號（Tacho）進行閉環調速，實現穩定運行；

• 軟啟動與加減速功能：提升系統穩定性，降低啟動沖擊；

• 反向控制與制動控制：具備快速制動能力，適用于反復啟停作業；

• 過載與過流保護功能：板載保護邏輯可防止負載異常造成損害。

英文資料：

Technical Description of GE 193X644AAG02 DC Motor Driver Board

Product model: 193X644AAG02

Product Name: DC Motor Drive Board

Series: GE 193X series industrial control module

Manufacturer: General Electric (GE)

product overview

GE 193X644AAG02 is a modular drive board designed specifically for controlling DC motor drive systems, widely used in industrial automation equipment, power control systems, and mechatronics devices. This board has high reliability, high response speed, and precise speed regulation capability, suitable for occasions with high requirements for motor starting, speed regulation, braking, and forward/reverse control.

Technical Parameter

Power supply voltage: 24V DC or ± 15V (depending on system configuration)

Drive current: Supports DC motors with a controlled power range of 0.5kW to 10kW

Control mode: PWM control/analog signal control

Response time:<1ms

Signal interface: Standard 193X gold finger edge connector

Cooling method: natural air cooling/system cooling

Core functions

DC motor drive control: achieve precise voltage and current regulation, control motor start stop, speed regulation, and steering;

Speed and current closed-loop control: capable of receiving speed measurement signals (Tacho) for closed-loop speed regulation, achieving stable operation;

Soft start and acceleration/deceleration function: improves system stability and reduces startup shock;

Reverse control and braking control: with fast braking capability, suitable for repeated start stop operations;

Overload and overcurrent protection function: The onboard protection logic can prevent damage caused by abnormal loads.
