GE 193X489AAG01系統卡
1.產 品 資 料 介 紹：
中文資料：
產品名稱：系統卡（System Card）
產品型號：193X489AAG01
制造商：General Electric (GE)
產品系列：193X 控制系統系列
功能概述
GE 193X489AAG01 是用于 GE 工業控制系統中的關鍵系統控制模塊，通常作為中央?yún)f(xié)調與通信的核心板卡，管理各個子模塊之間的數據通信、邏輯信號處理和控制信號調度。
核心功能
系統邏輯管理：作為系統控制中心，處理協調各板卡之間的邏輯關系
通信接口橋接：實現信號同步、數據共享與命令傳遞
故障檢測與中斷管理：可檢測系統錯誤，發出告警或保護信號
供電調配與信號分配：管理信號線路及部分控制電源分配
支持自診斷功能（依系統配置）
技術參數（典型）
| 項目 | 參數說明 |
|---|---|
| 工作電壓 | ±15V 或 5V DC（系統供電） |
| 輸入信號類型 | TTL、模擬信號、控制指令 |
| 輸出接口 | 標準 193X 插槽輸出，連接至控制板、接口板等 |
| 板卡類型 | 多層 PCB，插拔式結構 |
| 工作溫度范圍 | 0°C ～ 60°C |
| 抗干擾設計 | 多級濾波與信號緩沖保護 |
| 系統兼容性 | 與 GE 193X 所有主板、驅動板、接口板兼容運行 |
典型應用場景
GE Speedtronic 控制系統的中央邏輯處理模塊
驅動系統中管理控制信號流通與反饋調度
多控制板卡之間的橋接中樞
工業自動化系統的邏輯主控模塊
英文資料：
Product Name: System Card
Product model: 193X489AAG01
manufacturer: General Electric (GE)
Product Series: 193X Control System Series
FUNCTIONAL OVERVIEW
GE 193X489AAG01 is a critical system control module used in GE industrial control systems, typically serving as the core board for central coordination and communication, managing data communication, logic signal processing, and control signal scheduling between various submodules.
Core functions
System logic management: As the system control center, it handles and coordinates the logical relationships between various boards
Communication interface bridging: achieving signal synchronization, data sharing, and command transmission
Fault detection and interrupt management: capable of detecting system errors, issuing alarms or protection signals
Power supply allocation and signal distribution: managing signal lines and partial control power distribution
Support self diagnostic function (according to system configuration)
Technical parameters (typical)
Project parameter description
Working voltage ± 15V or 5V DC (system power supply)
Input signal type TTL, analog signal, control instruction
Output interface standard 193X slot output, connected to control board, interface board, etc
Board type: multi-layer PCB, plug-in structure
Working temperature range: 0 ° C to 60 ° C
Multi level filtering and signal buffering protection for anti-interference design
System compatibility is compatible with all motherboards, driver boards, and interface boards of GE 193X for operation
Typical application scenarios
Central Logic Processing Module of GE Speedtronic Control System
Management control signal flow and feedback scheduling in the drive system
Bridge hub between multiple control boards
Logic main control module of industrial automation system
