GE 193X460ADG02控制板
1.產 品 資 料 介 紹：
中文資料：
產品型號：193X460ADG02
產品名稱：控制板（Control Board）
制造商：General Electric（GE）
產品系列：193X 控制系統
功能描述：
193X460ADG02 是 GE 193X 系列控制系統中的一款多功能控制板，用于邏輯控制、信號調理、狀態傳輸?shù)龋钦麄€(gè)控制系統中的核心部件之一。該模塊常被用于調速系統、發電機組控制系統或其他大型工業控制平臺。
主要技術參數（典型配置）：
輸入電源：由系統供電（常見 ±15V DC、+5V DC）
信號類型：模擬與數字混合
輸出功能：控制信號輸出、狀態反饋、繼電器驅動
接口方式：插卡式，符合 GE 193X 系統背板標準
板載元件：集成電路、運放、晶體管、繼電器、精密電阻、電解電容等
應用領域：
GE Mark 系列汽輪機控制系統（如 Mark I、Mark II）
工業電機調速系統（尤其為大型交流/直流電機）
火力發電廠、變電站控制室
冶金、化工、重工業自動化平臺
使用與維護建議：
板卡插入時需斷電，確保接口清潔無異物
定期檢查電容是否有鼓包、漏液情況
使用示波器檢查輸出端是否存在波形異常
遇到邏輯錯誤、信號異常，應重點檢測控制IC與晶體管元件
若板卡損壞，建議尋找原型號備件或聯系專業維修機構進行翻修
英文資料：
Product model: 193X460ADG02
Product Name: Control Board
manufacturer: General Electric（GE）
Product Series: 193X Control System
Function description:
193X460ADG02 is a multifunctional control board in the GE 193X series control system, used for logic control, signal conditioning, status transmission, etc. It is one of the core components of the entire control system. This module is often used in speed control systems, generator control systems, or other large industrial control platforms.
Main technical parameters (typical configuration):
Input power supply: Powered by the system (commonly ± 15V DC,+5V DC)
Signal type: mixed analog and digital
Output function: Control signal output, status feedback, relay drive
Interface method: plug-in card, compliant with GE 193X system backplane standard
Onboard components: integrated circuits, operational amplifiers, transistors, relays, precision resistors, electrolytic capacitors, etc
Application areas:
GE Mark series turbine control system (such as Mark I, Mark II)
Industrial motor speed control system (especially for large AC/DC motors)
Control rooms for thermal power plants and substations
Metallurgical, chemical, and heavy industry automation platforms
Usage and maintenance suggestions:
Power off when inserting the board to ensure that the interface is clean and free of foreign objects
Regularly check whether the capacitor has bulges or leaks
Use an oscilloscope to check for waveform abnormalities at the output terminal
When encountering logic errors or signal anomalies, it is important to focus on detecting control ICs and transistor components
If the board is damaged, it is recommended to search for prototype spare parts or contact a professional repair organization for refurbishment
