GE 193X456AAG03繼電器卡
1.產 品 資 料 介 紹：
中文資料：
產品信息
產品型號：193X456AAG03
產品名稱：繼電器卡（Relay Card）
制造商：General Electric (GE)
產品系列：193X 控制系統模塊
產品功能
193X456AAG03 是 GE 193X 系列控制系統中的一塊 繼電器控制卡，其核心功能是通過邏輯控制信號，驅動板載繼電器，實現高低壓電路之間的隔離與控制。主要應用于驅動命令、電路切換、報警輸出等。
技術特點
| 項目 | 描述 |
|---|---|
| 控制方式 | 由控制系統邏輯板卡（如 CPU、驅動卡）發出觸發信號 |
| 輸出類型 | 電氣繼電器觸點輸出（常開/常閉） |
| 通道數量 | 多通道（通常4-8個繼電器） |
| 電氣隔離 | 繼電器動作提供輸入輸出電氣隔離 |
| 安裝結構 | 插卡式，安裝于193X系統標準機架中 |
典型應用場景
控制大功率電接觸器、斷路器、勵磁電路等
作為執行邏輯的物理輸出單元
發出報警、狀態反饋信號
實現遠程電氣操作或系統聯動控制
維護與故障排查建議
繼電器觸點粘連：使用萬用表檢測觸點是否機械卡滯
信號不響應：檢查控制信號輸入端是否正常
電磁線圈損壞：檢測繼電器線圈電阻是否正常（開路/短路）
接插件松動：檢查插槽及連接排線是否牢靠
英文資料：
PRODUCT INFORMATION
Product model: 193X456AAG03
Product Name: Relay Card
manufacturer: General Electric (GE)
Product Series: 193X Control System Module
PRODUCT FUNCTION
193X456AAG03 is a relay control card in the GE 193X series control system. Its core function is to drive onboard relays through logic control signals, achieving isolation and control between high and low voltage circuits. Mainly used for driving commands, circuit switching, alarm output, etc.
FEATURES
Project Description
The control mode is triggered by the logic board of the control system (such as CPU, driver card) issuing a trigger signal
Output type: Electrical relay contact output (normally open/normally closed)
Multiple channels (usually 4-8 relays)
Electrical isolation relay action provides input and output electrical isolation
Installation structure plug-in card, installed in the standard rack of 193X system
Typical application scenarios
Control high-power electrical contactors, circuit breakers, excitation circuits, etc
As a physical output unit for executing logic
Send out alarm and status feedback signals
Realize remote electrical operation or system linkage control
Maintenance and troubleshooting suggestions
Relay contact adhesion: Use a multimeter to check if the contacts are mechanically stuck
Signal not responding: Check if the control signal input terminal is normal
Electromagnetic coil damage: Check if the resistance of the relay coil is normal (open circuit/short circuit)
Loose connectors: Check if the slots and connecting cables are secure
2.產 品 展 示
3.其他產品
4.其他英文產品
