GE 193X376AB-GO1變頻卡
1.產 品 資 料 介 紹：
中文資料：
GE 193X376AB-G01 變頻卡（Inverter or Variable Frequency Card） 是 GE 193X 系列控制系統中的專用控制模塊，主要用于電機控制系統中的頻率調制和驅動信號生成。它廣泛應用于直流調速系統、交流變頻系統、發電控制和大型工業驅動中，作為調節電動機運行狀態的重要組成部分。
一、產品基本信息
產品型號：193X376AB-G01
產品名稱：變頻卡 / 變頻控制板
制造廠商：GE（General Electric）
所屬系列：193X 控制模塊
主要用途：電機驅動頻率調節、PWM控制、變頻輸出
二、主要功能
頻率控制
用于調節變頻驅動器的輸出頻率，實現對電動機轉速的精準控制，適用于變速驅動場合。PWM 調制輸出
生成脈寬調制（PWM）信號，驅動逆變器或功率模塊，控制輸出電壓/電流波形。調速功能
與速度反饋系統聯動，構成閉環調速控制，提高電機控制精度。保護功能
可集成過電流、過壓、欠壓等保護機制，保障系統安全運行。信號處理與隔離
對輸入控制信號進行處理、隔離、濾波等預處理操作，增強系統抗干擾能力。
三、典型技術參數（視具體系統配置而定）
輸入信號：模擬控制信號（0–10V、4–20mA）、數字控制信號
輸出形式：PWM 脈沖信號、變頻調制信號
支持頻率范圍：0.1 Hz 至數千 Hz（取決于配套硬件）
控制模式：開環 / 閉環調速控制
安裝方式：插拔式，適配 GE 193X 控制機架
工作溫度范圍：-10°C 至 +60°C
電氣隔離：具備輸入/輸出通道隔離功能
英文資料：
The GE 193X376AB-G01 Inverter or Variable Frequency Card is a specialized control module in the GE 193X series control system, mainly used for frequency modulation and drive signal generation in motor control systems. It is widely used in DC speed control systems, AC frequency conversion systems, power generation control, and large-scale industrial drives as an important component for regulating the operating status of electric motors.
1、 Basic Product Information
Product model: 193X376AB-G01
Product Name: Variable Frequency Card/Variable Frequency Control Board
Manufacturer: GE（General Electric）
Series: 193X Control Module
Main applications: Motor drive frequency regulation, PWM control, variable frequency output
2、 Main functions
frequency control
Used to adjust the output frequency of variable frequency drives, achieving precise control of motor speed, suitable for variable speed drive applications.
PWM modulation output
Generate pulse width modulation (PWM) signals to drive inverters or power modules and control output voltage/current waveforms.
Speed regulation function
Linked with the speed feedback system, it forms a closed-loop speed control to improve the accuracy of motor control.
Protection function
It can integrate overcurrent, overvoltage, undervoltage and other protection mechanisms to ensure the safe operation of the system.
Signal processing and isolation
Preprocess input control signals by processing, isolating, filtering, and other operations to enhance the system's anti-interference ability.
3、 Typical technical parameters (depending on specific system configuration)
Input signals: analog control signal (0-10V, 4-20mA), digital control signal
Output form: PWM pulse signal, variable frequency modulation signal
Supported frequency range: 0.1 Hz to several thousand Hz (depending on supporting hardware)
Control mode: open-loop/closed-loop speed control
Installation method: plug-in, compatible with GE 193X control rack
Working temperature range:- 10 ° C to+60 ° C
Electrical isolation: with input/output channel isolation function
2.產 品 展 示
