GE   DS200FCSAG1A電流感應界面板

1.產 品 資 料 介 紹：

中文資料：

DS200FCSAG1A
類型：電流感應界面板（Current Sensing Interface Board）

制造商

General Electric (GE) – Mark V Speedtronic 系統配件

功能簡介

DS200FCSAG1A 是用于 GE Mark V 控制系統中的一種專用信號接口板卡，其主要功能是采集和處理來自電流互感器（CT）的模擬信號，并將這些信號以適合處理的形式傳遞給主控制處理單元。它在電力設備的監控與保護系統中起到了關鍵的信號轉換和隔離作用。

主要功能與特性

1. 電流信號處理

   • 接收多個電流互感器（CT）的低電平信號

   • 實現多路輸入的轉換、隔離與濾波

2. 信號調理

   • 將 CT 信號調整至可供控制板（如 TCQA、TCCB 等）讀取的標準模擬量范圍

3. 保護功能

   • 提供過壓保護與噪聲濾波功能，防止電涌損壞系統

4. 板卡接口

   • 通過插針或邊緣連接器與背板通信，確保數據安全傳輸

5. 電隔離性能

   • 有效防止高壓干擾影響到控制系統

適配系統

• 適用于 GE Mark V Speedtronic 控制系統

• 通常用于 燃?xì)廨啓C(jī)、蒸汽輪機、發電機等電力設備 的電流監測系統

典型應用領域

1. 燃?xì)廨啓C(jī)發電站

   • 實時監控各相電流狀態

   • 用于過載保護、失步保護等控制策略

2. 大型工業電機控制

   • 電流檢測用于判斷負載運行狀態

   • 檢測電流異常、防止燒毀電機

3. 配電自動化系統

   • 精確記錄各分支電流值

   • 輔助負載均衡與故障分析

4. 發電廠 DCS 控制平臺

   • 與其它模擬輸入卡（如 STCA）聯合使用，實現電氣量綜合采集

技術優勢

• 高可靠性：適用于高溫高濕等惡劣環境

• 信號穩定：提供良好的信號濾波與抑噪功能

• 模塊化：便于維護與替換

• 與 GE Mark V 平臺無縫集成

英文資料：

DS200FCSAG1A

Type: Current Sensing Interface Board

manufacturer

General Electric (GE) - Mark V Speedtronic System Accessories

Function Introduction

DS200FCSAG1A is a dedicated signal interface board used in GE Mark V control systems. Its main function is to collect and process analog signals from current transformers (CTs), and transmit these signals to the main control processing unit in a suitable processing form. It plays a crucial role in signal conversion and isolation in the monitoring and protection system of power equipment.

Main functions and features

Current signal processing

Receive low-level signals from multiple current transformers (CTs)

Realize the conversion, isolation, and filtering of multiple inputs

signal-conditioning

Adjust the CT signal to the standard analog range that can be read by the control board (such as TCQA, TCCB, etc.)

Protection function

Provide overvoltage protection and noise filtering functions to prevent surge damage to the system

Board interface

Communicate with the backplane through pins or edge connectors to ensure secure data transmission

Electrical isolation performance

Effectively prevent high-voltage interference from affecting the control system

adaptation system

Suitable for GE Mark V Speedtronic control system

Current monitoring systems commonly used for power equipment such as gas turbines, steam turbines, generators, etc

Typical application areas

gas power station

Real time monitoring of the current status of each phase

Used for control strategies such as overload protection and out of step protection

Large industrial motor control

Current detection is used to determine the operating status of the load

Detect abnormal current and prevent motor burnout

distribution automation system

Accurately record the current values of each branch

Auxiliary load balancing and fault analysis

Power plant DCS control platform

Used in conjunction with other analog input cards (such as STCA) to achieve comprehensive collection of electrical quantities

Technical advantages

High reliability: suitable for harsh environments such as high temperature and humidity

Signal stability: provides good signal filtering and noise suppression functions

Modularization: easy to maintain and ｒｅｐｌａｃｅ

Seamless integration with GE Mark V platform
