GE DS200DDTBG2A驅動器
1.產 品 資 料 介 紹：
中文資料：
產品名稱：DS200DDTBG2A
制造商：GE (General Electric)
產品類型：數字I/O接口板（Digital Distributed Terminal Board）
系列平臺：Mark V 系統
一、產品概述
DS200DDTBG2A 是 GE Mark V 控制系統中的一款數字信號接口板，主要用于采集現場設備的數字輸入信號，以及輸出控制指令到執行設備。它是 G2 修訂型號，屬于 DS200DDTBGx 系列的第二種變體，帶有優化的I/O分配與更高的通道兼容性。
二、主要功能
數字輸入采集：連接如開關、繼電器觸點、限位器、傳感器等信號源。
數字輸出控制：控制繼電器線圈、電磁閥、報警器等。
與主控處理器通信：通過背板總線將輸入/輸出數據傳送至主控板。
狀態監測：通過板上LED燈監控每一通道的狀態，方便調試與運維。
三、產品特點
提供多通道數字輸入/輸出接口，適配復雜工業應用。
帶光電隔離保護，提高系統抗干擾性能和運行穩定性。
具有自檢與故障指示功能，利于現場故障快速排查。
支持熱插拔與模塊化替換，維護便利。
可配置性強，適配多種控制邏輯需求。
四、應用領域
該模塊廣泛用于以下工業控制系統中，主要處理設備間的信號交互：
燃?xì)廨啓C(jī)與蒸汽輪機控制系統：輸入/輸出開關量信號，用于保護、連鎖邏輯控制。
發電廠 DCS/自動化系統：作為接口層連接現場設備與主控制單元。
工業自動化系統：用于設備啟停控制、門禁信號、限位傳感反饋等應用。
冶金、石化、機械制造等自動控制系統：實現對輔助設備的精準控制。
英文資料：
Product Name: DS200DDTBG2A
manufacturer: GE (General Electric)
Product type: Digital Distributed Terminal Board
Series platform: Mark V system
1、 Product Overview
DS200DDTBG2A is a digital signal interface board in the GE Mark V control system, mainly used to collect digital input signals from field devices and output control instructions to executing devices. It is a G2 revised model, belonging to the second variant of the DS200DDTBGx series, with optimized I/O allocation and higher channel compatibility.
2、 Main functions
Digital input acquisition: Connect signal sources such as switches, relay contacts, limiters, sensors, etc.
Digital output control: controls relay coils, solenoid valves, alarms, etc.
Communication with the main control processor: Input/output data is transmitted to the main control board through the backplane bus.
Status monitoring: Monitor the status of each channel through LED lights on the board for easy debugging and operation.
3、 Product Features
Provide multi-channel digital input/output interfaces to adapt to complex industrial applications.
Equipped with photoelectric isolation protection, it improves the system's anti-interference performance and operational stability.
It has self checking and fault indication functions, which facilitate rapid troubleshooting on site.
Support hot plugging and modular replacement, easy maintenance.
Strong configurability, adaptable to various control logic requirements.
4、 Application Fields
This module is widely used in the following industrial control systems, mainly processing signal interaction between devices:
Gas turbine and steam turbine control system: Input/output switch signal, used for protection and interlock logic control.
Power plant DCS/automation system: serves as an interface layer to connect on-site equipment with the main control unit.
Industrial automation system: used for equipment start stop control, access control signals, limit sensing feedback and other applications.
Automatic control systems for metallurgy, petrochemicals, mechanical manufacturing, etc.: achieve precise control of auxiliary equipment.
2.產 品 展 示
