AMAT Applied Materials 0090-04150電源模塊

1.產 品 資 料 介 紹：

關鍵規格

功能特點

• 全球通用輸入：90–264?VAC 寬范圍輸入，可在不同電網條件下穩定工作。
• 高精度輸出：24?V?DC 輸出，精度 ±1%，紋波 ≤200?mVp?p，適合對電源質量要求高的設備。
• 多重保護：具備過壓、過流、短路、過熱保護，確保模塊及負載安全。
• 電氣隔離：輸入與輸出之間 4000?VAC 隔離，有效抑制電磁干擾。
• 高效節能：效率 ≥88%，降低能耗與散熱需求。

AMAT Applied Materials 0090-04150電源模塊  英文資料：

AMAT Applied Materials 0090-04150 is a single output AC-DC power module designed for semiconductor equipment. It can convert 90-264 VAC mains power to a stable 24V DC output, with a rated power of 120 W and complete protection and industrial grade reliability.

Key specifications

Project Specification Description

Input voltage 90-264 VAC automatically adapts to global power supply

Input frequency 47-63 Hz standard industrial frequency

Output voltage 24 ? V ? DC typical ± 1% accuracy

Output current of 5A meets the requirements of most control circuits

When the power factor is ≥ 0.95 at 230 VAC

Efficiency ≥ 88% typical value

Ripple noise ≤ 200 mVp-p low-noise design

Protection function: automatic recovery for overvoltage, overcurrent, short circuit, and overheating

Isolation voltage 4000 VAC input-output isolation

Operating temperature 0-50 ℃, suitable for industrial environments

Installation method: 35mm DIN rail/panel flexible installation

Size 140 ? mm × 68 ? mm × 32 ? mm Compact structure

Features

Global universal input: 90-264 VAC wide range input, capable of stable operation under different grid conditions.

High precision output: 24V DC output, accuracy ± 1%, ripple ≤ 200 mVp-p, suitable for devices with high power quality requirements.

Multiple protection: equipped with overvoltage, overcurrent, short circuit, and overheating protection to ensure the safety of modules and loads.

Electrical isolation: 4000 VAC isolation between input and output effectively suppresses electromagnetic interference.

Efficient and energy-saving: Efficiency ≥ 88%, reducing energy consumption and heat dissipation requirements.

 AMAT Applied Materials 0090-04150電源模塊 產品展示

 產品視頻
